- Mounting Type
- clip-on
- Connection Type
- Tension Clamp
- Current
- 57 A
- Maximum Voltage
- 800 V
- Material
- Wemid
- Standards
- IEC 60947-7-1, UL E60693
- Storage temperature, max.
- 40 °C
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, min.
- 0.5 mm²
- Wire connection cross section AWG, min.
- AWG 22
- Wire cross section max. (IECEX)
- 10 mm²
- Power loss in accordance with IEC 60947-7-x
- 1.31 W
- End cover plate required
- Yes
- Wire connection cross-section, solid core, min.
- 0.5 mm²
- Approvals
- CE, CSA, CURUSEX, DEMKOATEX, DNV GL, EAC, IECEXULD, INMETRO, KEMAATEX, KEMAKEUR, LLOYDSREG, MARITREG, RINA, UR
- Rated cross-section
- 6 mm²
- Wire cross section min. (CSA)
- 20 AWG
- Rated current
- 41 A
- Pollution severity
- 3
- Wire connection cross-section, finely stranded, min.
- 0.5 mm²
- Number of clamping points per level
- 2
- Continuous operating temp., max.
- 120 °C
- Storage temperature
- 10°C...40°C
- Twin wire-end ferrules, min.
- 0.5 mm²
- Certificate No. (IECEX)
- IECEXULD15.0008U
- Version
- Tension-clamp connection, for plug-in cross-connector, One end without connector
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/4, max.
- 6 mm²
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, max.
- 6 mm²
- Twin wire-end ferrules, max.
- 2.5 mm²
- Number of similar terminals
- 1
- Marking EN 60079-7
- Ex eb II C Gb
- Clamping range, max.
- 10 mm²
- Certificate No. (CSA)
- 200039-1152892
- Wire connection cross-section, solid core, max.
- 10 mm²
- Number of Levels
- 1
- Connection direction
- top
- Rail
- TS 35
- Wire connection cross-section, finely stranded with wire-end ferrules DIN 46228/1, min.
- 0.5 mm²
- Number of connections
- 2
- Certificate No. (ATEX)
- KEMA97ATEX2521U
- Number of potentials per tier
- 1
- Volume resistance according to IEC 60947-7-x
- 0.78 mΩ
- Continuous operating temp., min.
- -50 °C
- Wire connection cross section AWG, max.
- AWG 8
- Gauge to IEC 60947-1
- A5
- Rated impulse withstand voltage
- 8 kV
- Wire connection cross section, finely stranded, max.
- 10 mm²
- PE connection
- No
- Storage temperature, min.
- 10 °C
- Clamping range, min.
- 0.22 mm²
- UL 94 flammability rating
- V-0
- Operating Temperature Range
- For operating temperature range see EC Design Test Certificate / IEC Ex-Certificate of Conformity
- Open sides
- right
