Tower Light Module, 24V DC, Blue, 40 mm Dia., 59 mm Height, LED, KombiSIGN 40 Series

  • Mfr # 63454055

  • Zoro # G6276809


product price: $118.99
/ea
Free Shipping & Returns

Key Features

Standards
CE, cULus Listed, EAC, RoHS, UKCA, WEEE
Voltage
24V DC
Overall Diameter
40 mm
Housing Material
Polycarbonate
Lighting Technology
LED
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
63454055
Zoro #
G6276809
UPC #
-
Country of Origin
Germany

Dimensions

Overall Diameter
40 mm
Overall Height
59 mm
Height
2.312 in
Diameter
40 mm
Length
1.578 in
Width
1.58 in

Details

Item
Tower Light Module
Standards
CE, cULus Listed, EAC, RoHS, UKCA, WEEE
Voltage
24V DC
Housing Material
Polycarbonate
Lighting Technology
LED
Current Drawn
0.065A
Flashes per Minute
60
Color
Blue
Tower Light Series
KombiSIGN 40
Lens Material
Polycarbonate
For Use With
KombiSIGN 40 Series Stacklights
Sound Modes
Pulse
Operating Temp.
-22 Degrees to 140 Degrees F
Lens Design
Fresnel
Lamp Life
50,000 hr
Tower Light Color
Blue
NEMA Rating
NEMA 12
Light Color
Clear
Operating Voltage
24V DC
Compatible Series
KombiSIGN 40
For Location
Indoor, Outdoor
Operating Temperature - Maximum
60 Degrees C
Operating Temperature - Minimum
-30 Degrees C
Lifespan
50,000 hr
Light Operating Mode
Flashing, Strobe
Light Source
LED
Operating Current
0.065 A
Number of Lamps
2
IP Rating
IP66, IP69K
Lens Shape
Dome

Description

Tower Light Series KombiSIGN 40, Voltage 24V DC, Tower Light Color Blue, Sound Modes Pulse, Diameter 40 mm, NEMA Rating NEMA 12, Lighting Technology LED, 60 Flashes per Minute, Lamp Life 50,000 hr, Housing Material Polycarbonate, Lens Design Fresnel, Lens Material Polycarbonate, Operating Temp. -22 Degrees to 140 Degrees F, Standards CE, cULus Listed, EAC, RoHS, UKCA, WEEE, Current Drawn 0.065A, Height 2.312 in, Length 1.578 in, Width 1.58 in, For Use With KombiSIGN 40 Series Stacklights
