White-Rodgers Fan/Limit Control 05D51 078S1 - main

Fan/Limit Control

  • Mfr # 05D51 078S1

  • Zoro # G1927581

product price: $138.99
/ea
Free Shipping & Returns

Key Features

Temp. Range (F)
Fan 50 to 265, Limit 100 to 300
Type
Adjustable Temp, Auto Reset
Switch Type
SPDT
Depth (In.)
1 5/8 in
Width (In.)
3 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
05D51 078S1
Zoro #
G1927581
UPC #
786710002311
Country of Origin
Mexico

Dimensions

Depth (In.)
1 5/8 in
Width (In.)
3 in
Height (In.)
4 3/8 in
Element Insertion Length (In.)
11 in
Insertion Length
11 in
Overall Depth
1 5/8 in
Overall Height
4 1/4 in
Overall Width
2 7/8 in

Details

Item
Fan and Limit Control
Temp. Range (F)
Fan 50 to 265, Limit 100 to 300
Type
Adjustable Temp, Auto Reset
Switch Type
SPDT
Switch Closes @ (F)
265 Degrees F
Element Type
Bi-Metal Rod
Fan On Temp. (F)
265 Degrees F
Inductive Amps @ 240V
10 A
Fan Off Temp. (F)
50 Degrees F
Inductive Amps @ 120V
6 A
Differential
Fan Fixed 25 Degrees F, Fan Adj. 15 Degrees F
Switch Action
Fan - Close on Rise, Limit - Open on Rise
Contact Amp Rating @ 24V
Fan 5.6 Limit 6.0
Minimum Temperature Differential Setting
15 Degrees F
Differential Adjustability
Adjustable
Temperature Differential
15 Degrees F; 25 Degrees F
Reset Type
Automatic Reset
Standards
CSA Certified, UL Listed
Application
Fan and Limit Control
Switch Closing Temperature
100 Degrees F, 265 Degrees F
Switch Opening Temperature
50 Degrees F, 300 Degrees F
Product Type
Fan and Limit Control
Contact Rating (AC)
FLA: 10 A @ 120V, FLA: 14 A @ 120V, FLA: 5.6 A @ 24V, FLA: 6 A @ 24V, FLA: 6 A @ 240V, FLA: 7 A @ 240V
Maximum Temperature Differential Setting
25 Degrees F
Limit Minimum Control Temperature
100 Degrees F
Maximum Operating Temperature
300 Degrees F
Input Voltage
120V AC, 240V AC, 24V AC
Fan Maximum Control Temperature
265 Degrees F
Contact Form
SPDT
Mounting
Plenum Mount
Fan Minimum Control Temperature
50 Degrees F
Limit Maximum Control Temperature
300 Degrees F

Description

Fan and Limit Control, Application Fan and Limit Control, Mounting Plenum Mount, Contact Form SPDT, Switch Action Fan - Close on Rise, Limit - Open on Rise, Reset Type Automatic Reset, Fan Minimum Control Temperature 50 Degrees F, Fan Maximum Control Temperature 265 Degrees F, Limit Maximum Control Temperature 300 Degrees F, Limit Minimum Control Temperature 100 Degrees F, Differential Adjustability Adjustable, Maximum Temperature Differential Setting 25 Degrees F
