  9. Switching Relay, NO, Single Phase, 4 Pins
No Product Image Available

Switching Relay, NO, Single Phase, 4 Pins

  • Mfr # 49M11-843

  • Zoro # G202685484

product price: $66.89
/ea

Key Features

For Use With
Contactors for Air Conditioning and Refrigeration
Coil Volts
120V AC, 208/240V AC, 24V AC
Full Load Amps @ 120VAC
40 A
Standards
CSA LR13360, UL E12139, UL E22381
Phase
Single
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
49M11-843
Zoro #
G202685484
UPC #
786710561757
Country of Origin
Mexico

Dimensions

Height (In.)
2 3/8 in
Depth (In.)
3 7/8 in
Width (In.)
2 3/4 in
Overall Length
3 7/8 in
Overall Width
2 3/4 in
Overall Depth
2 3/8 in

Details

Item
Switching Relay
For Use With
Contactors for Air Conditioning and Refrigeration
Coil Volts
120V AC, 208/240V AC, 24V AC
Full Load Amps @ 120VAC
40 A
Standards
CSA LR13360, UL E12139, UL E22381
Phase
Single
Agency Compliance
UL Recognized to UL60730-1
Type
Multi-Volt Universal Contactor
Application
Heat Pumps, Refrigeration, Air Conditioning
Voltage
120V AC, 208/240V AC, 24V AC
Design
Multi-Volt Coil
Mounting Style
Bracket
Frequency
50/60 Hz
Operating Humidity - Minimum
5 %
Full Load Current @ 240V AC
40 A
Switch Action
Normally Open
Number of Pins
4
Contact Form
SPST
Locked Rotor Current @ 120V AC
200 A
Number of Relays
1
Low Voltage Contact Form
DPST
Electrical Connection Type
Quick Connect Terminals
Locked Rotor Current @ 240V AC
200 A
Horsepower @ 120V AC
Not Rated
Horsepower @ 240V AC
Not Rated
Full Load Current @ 120V AC
40 A
Operating Temperature - Maximum
158 Degrees F
Operating Temperature - Minimum
-40 Degrees F

Description

Emerson 49P11-843 Sure Switch Relay

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
