Widia Grooving/Parting Insert, NF-K, Carbide NF3M300RK - main

Grooving/Parting Insert, NF-K, Carbide

  • Mfr # NF3M300RK

  • Zoro # G3598705

product price: $26.69
/ea
Sold in multiples of 5 for $133.45

Key Features

Style
TopGroove(TM)
Insert Seat Size
3
Width
4.98mm
Chip-Breaker
Yes
Grade
TN6025
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
NF3M300RK
Zoro #
G3598705
UPC #
4021169737503
Country of Origin
United States

Dimensions

Insert Seat Size
3
Width
4.98mm
Insert Size
3
Corner Radius
0.25mm
Thickness
8.74mm
Depth of Cut
3.81mm
Max. Grooving Width
3.00mm
Seat Size
3

Details

Item
Parting and Grooving Insert
Style
TopGroove(TM)
Chip-Breaker
Yes
Grade
TN6025
Cutting Direction
Right Hand
ISO Number
NF3M300RK
Rake
10 Degrees
No. of Edges
2
Insert Material
Carbide
Insert Style
NF-K
Lead Angle
11 Degrees
Mounting Style
Notch
Application
Grooving
Coating
AlTiN
Material - Machining
Carbide
ANSI Code
NF3M300RK
Chip-Breaker Code
K
Primary Material Application
Nickel, Stainless Steel, Steel, Titanium
Hole Type
No Hole
Measurement System
Metric
Finish - Machining
AlTiN
Cutting Application
Grooving
Number of Cutting Edges
2
Secondary Material Application ISO Code
H, K, N
Feed Type
High
Chip-Breaker Style
On One Side
Manufacturer Grade
TN6025
Coating Process
PVD
Secondary Material Application
Aluminum, Brass, Bronze, Cast Iron, Copper, Hardened Steel
Clearance Angle
11 Degrees
Primary Material Application ISO Code
M, P, S

Description

Parting and Grooving Insert, Right Hand, Max. Grooving Width 3.00mm, ANSI Code NF3M300RK, Chip-Breaker Code K, Chip-Breaker Style On One Side, Clearance Angle 11 Degrees , Coating Process PVD
