Widia Indexable Insert Drill, 3/4", TCF TCF0688R5SLR075B - main

Indexable Insert Drill, 3/4", TCF

  • Mfr # TCF0688R5SLR075B

  • Zoro # G3777765

product price: $640.99
/ea
Free Shipping & Returns

Key Features

Diameter
3/4"
Ratio
5xD
Shank Dia.
3/4 in
Overall Length
6.3471 in
Cutting Direction
Right Hand
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TCF0688R5SLR075B
Zoro #
G3777765
UPC #
4050841103794
Country of Origin
Bulgaria

Dimensions

Diameter
3/4"
Shank Dia.
3/4 in
Overall Length
6.3471 in
Shank Length
1.9685 in
Depth x Dia. Ratio
5xD
Min. Drill Dia.
11/16 in
Max. Drilling Depth
3.4650 in
Flute Length
4.2210 in

Details

Item
Indexable Insert Drill
Ratio
5xD
Cutting Direction
Right Hand
Mounting Style
Screw Clamp
Flanged Shank
Yes
Number of Coolant Holes
2
Toolholder Style
TCF
Central Insert Style
TCF
Spiral Direction
Right Hand
Coolant Fed
Coolant Through
Drilling Application
45 Degrees Corner, Blind Hole, Chain, Convex, Cross Hole, Half Cylindrical, Inclined Entry, Inclined Exit
ANSI Code
TCF0688R5SLR075B
ISO Number
TCF0688R5SLR075B
Shank Type - Machining
Round with Flat and Side Lock
Flute Type
Slow Spiral
Number of Inserts
2
Measurement System
Fractional Inch

Description

Indexable Insert Drill, 5xD, Max. Drilling Depth 3.4650 in, TCF0688R5SLR075B, TCF, Coolant Through
