Indexable Profiling End Mill, M100 Series, High Speed Steel, 6.00mm Depth of Cut
Mfr # 12391020400
Zoro # G3802913
product price: $1,005.99
/ea
Free Shipping & Returns
Key Features
Series
M100
Overall Length
50.00mm
Depth of Cut
6.00mm
Material - Machining
High Speed Steel
Insert Size
1204
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
12391020400
Zoro #
G3802913
UPC #
4021169172021
Country of Origin
Czechia
Dimensions
Overall Length
50.00mm
Depth of Cut
6.00mm
Insert Size
1204
Max. Cutting Dia.
80.00mm
Arbor Dia.
27.00mm
Hub Outside Dia.
60.00mm
Details
Item
Indexable Profiling End Mill
Series
M100
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
Round
Insert Style
RD
Number of Inserts
6
Max. Speed
12,000 RPM
ANSI Code
12391020400
Features
Anti-Rotation Feature for Top Security
ISO Number
12391020400
Insert Holding Type
Screw
Coolant Fed
Coolant Through
Compatible Hardware
Insert Screw M3.5x0.6 x 8.9 T15, SHCS with Coolant Groove, Torx Wrench
Cutting Application
3D Profiling, Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Ball Nose, Slotting: Square End
Description
Indexable Profiling End Mill, Max. Cutting Dia. 80.00mm, Depth of Cut 6.00mm, Overall Length 50.00mm, ANSI Code 12391020400, Compatible Hardware Insert Screw M3.5x0.6 x 8.9 T15, SHCS with Coolant Groove, Torx Wrench, Coolant Fed Coolant Through, Cutting Application 3D Profiling, Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Ball Nose, Slotting: Square End
