Indexable Profiling End Mill, M100 Series, High Speed Steel, 8.00mm Depth of Cut
Mfr # 12391023400
Zoro # G3804149
product price: $699.99
/ea
Free Shipping & Returns
Key Features
Series
M100
Overall Length
40.00mm
Depth of Cut
8.00mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
12391023400
Zoro #
G3804149
UPC #
4021169171451
Country of Origin
Czechia
Dimensions
Overall Length
40.00mm
Depth of Cut
8.00mm
Insert Size
1606
Max. Cutting Dia.
50.00mm
Arbor Dia.
22.00mm
Hub Outside Dia.
40.00mm
Details
Item
Indexable Profiling End Mill
Series
M100
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
Round
ISO Number
12391023400
Number of Inserts
4
Insert Holding Type
Screw
Insert Style
RC
Features
Anti-Rotation Feature for Top Security
Coolant Fed
Coolant Through
ANSI Code
12391023400
Max. Speed
13,000 RPM
Compatible Hardware
Coolant Screw, Insert Screw M4.5x0.75 x 11 T20, Socket Head Screw DIN 912 M10
Cutting Application
3D Profiling, Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Ball Nose, Slotting: Square End
Description
Indexable Profiling End Mill, Max. Cutting Dia. 50.00mm, Depth of Cut 8.00mm, Overall Length 40.00mm, ANSI Code 12391023400, Compatible Hardware Coolant Screw, Insert Screw M4.5x0.75 x 11 T20, Socket Head Screw DIN 912 M10, Coolant Fed Coolant Through, Cutting Application 3D Profiling, Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Ball Nose, Slotting: Square End
