Indexable Profiling End Mill, M1200 Series, High Speed Steel, 1.70mm Depth of Cut
Mfr # M1200HF040Z05HN07
Zoro # G3802475
product price:Â $744.99
/ea
Free Shipping & Returns
Key Features
Series
M1200
Overall Length
40.00mm
Depth of Cut
1.70mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
M1200HF040Z05HN07
Zoro #
G3802475
UPC #
4021169601156
Country of Origin
United States
Dimensions
Overall Length
40.00mm
Depth of Cut
1.70mm
Insert Size
0704
Max. Cutting Dia.
54.14mm
Arbor Dia.
22.00mm
Hub Outside Dia.
38.00mm
Details
Item
Indexable Profiling End Mill
Series
M1200
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
120 Degrees Hexagon
Rake
-7 Degrees Axial, -8.6 Degrees Radial
ISO Number
M1200HF040Z05HN07
Features
First Choice for Low Depth of Cut Face Milling, High-Feed Capability, Twelve Cutting Edges
Cutting Application
Face Milling, Side and Face Milling
ANSI Code
M1200HF040Z05HN07
Number of Inserts
5
Coolant Fed
Coolant Through
Max. Speed
15,800 RPM
Insert Holding Type
Screw
Compatible Hardware
Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 T15, Torx Driver
Insert Style
HNGJ ANENLD
Description
Indexable Profiling End Mill, Max. Cutting Dia. 54.14mm, Depth of Cut 1.70mm, Overall Length 40.00mm, ANSI Code M1200HF040Z05HN07, Compatible Hardware Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 T15, Torx Driver, Coolant Fed Coolant Through, Cutting Application Face Milling, Side and Face Milling
