Indexable Profiling End Mill, M1200 Series, High Speed Steel, 1.70mm Depth of Cut
Mfr # M1200HF080Z08HN07
Zoro # G3803729
product price:Â $1,076.99
/ea
Free Shipping & Returns
Key Features
Series
M1200
Overall Length
50.00mm
Depth of Cut
1.70mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
M1200HF080Z08HN07
Zoro #
G3803729
UPC #
4021169606472
Country of Origin
United States
Dimensions
Overall Length
50.00mm
Depth of Cut
1.70mm
Insert Size
0704
Max. Cutting Dia.
94.12mm
Arbor Dia.
27.00mm
Hub Outside Dia.
60.00mm
Details
Item
Indexable Profiling End Mill
Series
M1200
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
120 Degrees Hexagon
Rake
-6.4 Degrees Radial, -7 Degrees Axial
Compatible Hardware
Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 T15, Torx Driver
Insert Holding Type
Screw
Number of Inserts
8
Features
First Choice for Low Depth of Cut Face Milling, High-Feed Capability, Twelve Cutting Edges
Insert Style
HNGJ ANENLD
ANSI Code
M1200HF080Z08HN07
ISO Number
M1200HF080Z08HN07
Coolant Fed
Coolant Through
Max. Speed
7,900 RPM
Cutting Application
Face Milling, Side and Face Milling
Description
Indexable Profiling End Mill, Max. Cutting Dia. 94.12mm, Depth of Cut 1.70mm, Overall Length 50.00mm, ANSI Code M1200HF080Z08HN07, Compatible Hardware Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 T15, Torx Driver, Coolant Fed Coolant Through, Cutting Application Face Milling, Side and Face Milling
