Indexable Profiling End Mill, M1200 Series, High Speed Steel, 3.50mm Depth of Cut
Mfr # M1200D040Z04HN07
Zoro # G3781773
product price:Â $678.99
/ea
Free Shipping & Returns
Key Features
Series
M1200
Overall Length
40.00mm
Depth of Cut
3.50mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
M1200D040Z04HN07
Zoro #
G3781773
UPC #
4021169655388
Country of Origin
Multiple
Dimensions
Overall Length
40.00mm
Depth of Cut
3.50mm
Insert Size
0704
Max. Cutting Dia.
48.71mm
Arbor Dia.
22.00mm
Hub Outside Dia.
38.00mm
Details
Item
Indexable Profiling End Mill
Series
M1200
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
120 Degrees Hexagon
Rake
-7 Degrees Axial, -8.7 Degrees Radial
Number of Inserts
4
ISO Number
M1200D040Z04HN07
Coolant Fed
Coolant Through
Features
First Choice for Low Depth of Cut Face Milling, Maximum Number of Teeth per Diameter, Twelve Cutting Edges
Compatible Hardware
Insert Screw M4x0.7 x 10 T15, Torx Driver
Max. Speed
15,800 RPM
Cutting Application
Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
ANSI Code
M1200D040Z04HN07
Insert Holding Type
Screw
Insert Style
HNGJ ANENLD
Description
Indexable Profiling End Mill, Max. Cutting Dia. 48.71mm, Depth of Cut 3.50mm, Overall Length 40.00mm, ANSI Code M1200D040Z04HN07, Compatible Hardware Insert Screw M4x0.7 x 10 T15, Torx Driver, Coolant Fed Coolant Through, Cutting Application Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
