Indexable Profiling End Mill, M1200 Series, High Speed Steel, 3.50mm Depth of Cut
Mfr # M1200D250Z06S075HN07
Zoro # G3799011
product price:Â $865.99
/ea
Free Shipping & Returns
Key Features
Series
M1200
Overall Length
40.00mm
Depth of Cut
3.50mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
M1200D250Z06S075HN07
Zoro #
G3799011
UPC #
4021169667411
Country of Origin
India
Dimensions
Overall Length
40.00mm
Depth of Cut
3.50mm
Insert Size
0704
Max. Cutting Dia.
72.20mm
Arbor Dia.
3/4"
Hub Outside Dia.
44.45mm
Details
Item
Indexable Profiling End Mill
Series
M1200
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
120 Degrees Hexagon
Rake
-6.5 Degrees Radial, -7 Degrees Axial
Compatible Hardware
3/8"-24 x 1 in Socket Head Cap Screw, Insert Screw M4x0.7 x 10 T15, Torx Driver
ISO Number
M1200D250Z06S075HN07
Cutting Application
Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
Insert Holding Type
Screw
Number of Inserts
6
ANSI Code
M1200D250Z06S075HN07
Insert Style
HNGJ ANENLD
Coolant Fed
Coolant Through
Features
First Choice for Low Depth of Cut Face Milling, Maximum Number of Teeth per Diameter, Twelve Cutting Edges
Max. Speed
10,000 RPM
Description
Indexable Profiling End Mill, Max. Cutting Dia. 72.20mm, Depth of Cut 3.50mm, Overall Length 40.00mm, ANSI Code M1200D250Z06S075HN07, Compatible Hardware 3/8 In.-24 x 1 in Socket Head Cap Screw, Insert Screw M4x0.7 x 10 T15, Torx Driver, Coolant Fed Coolant Through, Cutting Application Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
