Indexable Profiling End Mill, M1200 Series, High Speed Steel, 4.44mm Depth of Cut
Mfr # M1200D040Z04HN09
Zoro # G3802064
product price: $733.99
/ea
Free Shipping & Returns
Key Features
Series
M1200
Overall Length
40.00mm
Depth of Cut
4.44mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
M1200D040Z04HN09
Zoro #
G3802064
UPC #
4021169655586
Country of Origin
Czechia
Dimensions
Overall Length
40.00mm
Depth of Cut
4.44mm
Insert Size
0905
Max. Cutting Dia.
50.96mm
Arbor Dia.
22.00mm
Hub Outside Dia.
39.00mm
Details
Item
Indexable Profiling End Mill
Series
M1200
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
120 Degrees Hexagon
Rake
-7.6 Degrees Radial
Compatible Hardware
Insert Screw M4x0.7 x 10 T15, Torx Driver
Features
Low Cutting Forces for Maximum Productivity, Twelve Cutting Edges
Number of Inserts
4
Cutting Application
Side and Face Milling
Max. Speed
15,800 RPM
ISO Number
M1200D040Z04HN09
Insert Holding Type
Screw
Insert Style
HNGJ ANENLD
Coolant Fed
Coolant Through
ANSI Code
M1200D040Z04HN09
Description
Indexable Profiling End Mill, Max. Cutting Dia. 50.96mm, Depth of Cut 4.44mm, Overall Length 40.00mm, ANSI Code M1200D040Z04HN09, Compatible Hardware Insert Screw M4x0.7 x 10 T15, Torx Driver, Coolant Fed Coolant Through, Cutting Application Side and Face Milling
