Indexable Profiling End Mill, M1200 Series, High Speed Steel, 4.70mm Depth of Cut
Mfr # M1200HD200Z05S075HN07
Zoro # G3784040
product price:Â $806.99
/ea
Free Shipping & Returns
Key Features
Series
M1200
Overall Length
40.00mm
Depth of Cut
4.70mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
M1200HD200Z05S075HN07
Zoro #
G3784040
UPC #
4021169603525
Country of Origin
India
Dimensions
Overall Length
40.00mm
Depth of Cut
4.70mm
Insert Size
0704
Max. Cutting Dia.
57.56mm
Arbor Dia.
3/4"
Hub Outside Dia.
44.45mm
Details
Item
Indexable Profiling End Mill
Series
M1200
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Insert Shape
120 Degrees Hexagon
Rake
-7 Degrees Axial, -9.3 Degrees Radial
ANSI Code
M1200HD200Z05S075HN07
Number of Inserts
5
Insert Style
HNGJ ANENLD
Coolant Fed
Coolant Through
Compatible Hardware
3/8"-24 x 1 in Socket Head Cap Screw, Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 T15, Torx Driver
ISO Number
M1200HD200Z05S075HN07
Features
Higher AP1 Max with Standard Insert, Twelve Cutting Edges
Insert Holding Type
Screw
Cutting Application
Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
Max. Speed
12,500 RPM
Description
Indexable Profiling End Mill, Max. Cutting Dia. 57.56mm, Depth of Cut 4.70mm, Overall Length 40.00mm, ANSI Code M1200HD200Z05S075HN07, Compatible Hardware 3/8 In.-24 x 1 in Socket Head Cap Screw, Anti-Seize Lubricant, Insert Screw M4x0.7 x 10 T15, Torx Driver, Coolant Fed Coolant Through, Cutting Application Face Milling, Side and Face Milling, Side/Shoulder Milling: Eased Chamfer
