Indexable Profiling End Mill, VHSC Series, High Speed Steel, 16.00mm Depth of Cut
Mfr # VHSC050Z04S22XD16
Zoro # G3788441
product price: $708.99
/ea
Free Shipping & Returns
Key Features
Series
VHSC
Overall Length
45.00mm
Depth of Cut
16.00mm
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
VHSC050Z04S22XD16
Zoro #
G3788441
UPC #
4059782463158
Country of Origin
Multiple
Dimensions
Overall Length
45.00mm
Depth of Cut
16.00mm
Insert Size
16M508
Arbor Dia.
22.00mm
Hub Outside Dia.
45.00mm
Details
Item
Indexable Profiling End Mill
Series
VHSC
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Rake
-7.9 Degrees Radial, 7 Degrees Axial
Insert Shape
89.27 Degrees Parallelogram
ANSI Code
VHSC050Z04S22XD16
Coolant Fed
Coolant Through
Number of Inserts
4
Insert Holding Type
Screw
Features
Consistant Axial Gage Length with Insert Nose Radii From 0.008 in (0.2mm) up to 0.236 in (6mm), Only One Cutter Body Style to Load Inserts with Nose Radii from 0.008 in (0.2mm) up to 0.236 in (6mm), Productivity Booster up to 525in³/min (8600cm³/min) MRR at Machining Aluminum Components
Compatible Hardware
DP5009A, Torx Plus Drive Wrench
Max. Speed
30,000 RPM
ISO Number
VHSC050Z04S22XD16
Insert Style
XDET FRALP
Cutting Application
Face Milling, Helical Milling, Inclined Square End Mill, Pocketing, Ramping: Blank, Side and Face Milling
Description
Indexable Profiling End Mill, Depth of Cut 16.00mm, Overall Length 45.00mm, ANSI Code VHSC050Z04S22XD16, Compatible Hardware DP5009A, Torx Plus Drive Wrench, Coolant Fed Coolant Through, Cutting Application Face Milling, Helical Milling, Inclined Square End Mill, Pocketing, Ramping: Blank, Side and Face Milling
