Indexable Profiling End Mill, VSM11 Series, High Speed Steel, 11.53mm Depth of Cut
Mfr # VSM11D016Z02B16XD11
Zoro # G3803412
product price:Â $346.99
/ea
Free Shipping & Returns
Key Features
Series
VSM11
Overall Length
70.00mm
Depth of Cut
11.53mm
Material - Machining
High Speed Steel
Insert Size
110408
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
VSM11D016Z02B16XD11
Zoro #
G3803412
UPC #
4050839638932
Country of Origin
Canada
Dimensions
Overall Length
70.00mm
Depth of Cut
11.53mm
Insert Size
110408
Shank Dia.
16.00mm
Neck Dia.
13.81mm
Min. Cutting Dia.
16.00mm
Shank Length
49.00mm
Head Projection Length
21.00mm
Description
Indexable Profiling End Mill, Depth of Cut 11.53mm, Shank Dia. 16.00mm, Overall Length 70.00mm, ANSI Code VSM11D016Z02B16XD11, Compatible Hardware Insert Screw M2.5x0.45 x 5.9 T8, Torx Wrench TX8, Coolant Fed Coolant Through, Cutting Application Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side/Shoulder Milling: Square End
