Indexable Profiling End Mill, VSM17 Series, High Speed Steel, 15.80mm Depth of Cut
Mfr # VSM17D160Z12S40XD17
Zoro # G3793280
product price:Â $1,427.99
/ea
Free Shipping & Returns
Key Features
Series
VSM17
Overall Length
63.00mm
Depth of Cut
15.80mm
Material - Machining
High Speed Steel
Insert Size
1704
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowUnlock tax-exempt savings
Add Tax ExemptionSpecifications
Product Information
MFR #
VSM17D160Z12S40XD17
Zoro #
G3793280
UPC #
4056544118424
Country of Origin
Germany
Dimensions
Overall Length
63.00mm
Depth of Cut
15.80mm
Insert Size
1704
Arbor Dia.
40.00mm
Hub Outside Dia.
100.00mm
Details
Item
Indexable Profiling End Mill
Series
VSM17
Material - Machining
High Speed Steel
Cutting Direction
Right Hand
Rake
-3.3 Degrees Radial, 16 Degrees Axial
Features
Effective Internal Coolant Feature, Increased Ramping Capability, Precisely Reaching the Cutting Edge, Superior Wall and Surface Finish Capabilities, True 90 Degrees Capability
Side Cutting Edge Angle
90 Degrees
Coolant Fed
Coolant Through
Insert Holding Type
Screw
Max. Speed
13,300 RPM
ANSI Code
VSM17D160Z12S40XD17
Compatible Hardware
Coolant Shower Plate, Coolant Spann Screw, Insert Screw M4x0.7 x 8.4 T15, Torx Wrench TX15
Insert Style
XD.T PE R
ISO Number
VSM17D160Z12S40XD17
Cutting Application
Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End
Number of Inserts
12
Description
Indexable Profiling End Mill, Depth of Cut 15.80mm, Overall Length 63.00mm, ANSI Code VSM17D160Z12S40XD17, Compatible Hardware Coolant Shower Plate, Coolant Spann Screw, Insert Screw M4x0.7 x 8.4 T15, Torx Wrench TX15, Coolant Fed Coolant Through, Cutting Application Face Milling, Helical Milling, Pocketing, Ramping: Blank, Side and Face Milling, Side/Shoulder Milling: Square End, Slotting: Square End
