Widia Indexable Toolholder, DSDN, DSDNN3232P19KC06 - main

Indexable Toolholder, DSDN,

  • Mfr # DSDNN3232P19KC06

  • Zoro # G3786673

product price: $141.99
/ea
Free Shipping & Returns

Key Features

Insert Shape
Square
Number of Inserts Required
1
Shank Length
127.20mm
Overall Length
170.00mm
Cutting Length
19.0500mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
DSDNN3232P19KC06
Zoro #
G3786673
UPC #
4050841517560
Country of Origin
India

Dimensions

Shank Length
127.20mm
Overall Length
170.00mm
Cutting Length
19.0500mm
Insert Size
190612
Shank Width
32.00mm
Shank Height
32.00mm

Details

Item
Indexable Turning Toolholder
Insert Shape
Square
Number of Inserts Required
1
Shank
Square
Material
Steel
Rake
-7 Degrees Axial, 0 Degrees Radial
Cutting Direction
Neutral
Style
Negative
Clamp
Kenclamp
ISO Number
DSDNN3232P19KC06
Coolant Fed
Non-Coolant Through
Compatible Hardware
25IP Clamp Screw, 25IP Lock Pin, 25IP Shim Screw
ANSI Code
DSDNN3232P19KC06
Side Cutting Edge Angle
45 Degrees
Insert Clearance Angle
0 Degrees
Approach Angle
45 Degrees
Insert Holding Type
Clamp and Lock Pin
Toolholder Style
DSDN
Cutting Application
Facing, Profiling, Turning
Insert Style
SN
Material - Machining
High Speed Steel
Lead Angle
45 Degrees deg
Measurement System
Metric

Description

Indexable Turning Toolholder, DSDN, Insert Style SN, Overall Length 170.00mm
