Indexable Toolholder, MTJN,

  • Mfr # MTJNRS164

  • Zoro # G3786901


product price: $118.99
/ea
Free Shipping & Returns

Key Features

Rake
Double Negative
Cutting Length
0.8660"
Insert Shape
Triangle
Cutting Direction
Right Hand
Material
Steel
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
MTJNRS164
Zoro #
G3786901
UPC #
4021169423192
Country of Origin
Bulgaria

Dimensions

Cutting Length
0.8660"
Insert Size
432
Shank Length
4.6810 in
Overall Length
6 in
Head Length
1.3200 in
Shank Height
1 in
Shank Width
1 in

Details

Item
Indexable Turning Toolholder
Rake
Double Negative
Insert Shape
Triangle
Cutting Direction
Right Hand
Material
Steel
Shank
Square
Clamp
Top and Hole Clamping
Number of Inserts Required
1
Toolholder Style
MTJN
ANSI Code
MTJNRS164
Side Cutting Edge Angle
-3 Degrees
Insert Inscribed Circle
1/2 in
Insert Style
TN
Coolant Fed
Non-Coolant Through
Compatible Hardware
3/32 in Clamp Screw, 5/64 in Lock Pin
ISO Number
MTJNRS164
Insert Holding Type
Clamp and Lock Pin
Insert Clearance Angle
0 Degrees
Approach Angle
93 Degrees
Material - Machining
High Speed Steel
Lead Angle
-3 Degrees
Measurement System
Decimal Inch

Description

Indexable Turning Toolholder, MTJN, Insert Style TN, Overall Length 6 in
