Indexable Toolholder, SCLC,

  • Mfr # SCLCR083

  • Zoro # G3792334


product price: $102.99
/ea
Free Shipping & Returns

Key Features

Material
Steel
Shank Length
2-7/8 in
Clamp
Screw
Style
Screw-On
Cutting Length
0.3808"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SCLCR083
Zoro #
G3792334
UPC #
4021169422614
Country of Origin
United States

Dimensions

Shank Length
2-7/8 in
Cutting Length
0.3808"
Insert Size
32.52
Overall Length
3-1/2 in
Shank Height
1/2 in
Shank Width
1/2 in
Head Length
5/8 in

Details

Item
Indexable Turning Toolholder
Material
Steel
Clamp
Screw
Style
Screw-On
Number of Inserts Required
1
Shank
Square
Rake
0 Degrees Axial, 0 Degrees Radial
Insert Screw
T15
Insert Shape
80 Degrees Diamond
Cutting Direction
Right Hand
Insert Clearance Angle
7 Degrees
Insert Inscribed Circle
3/8 in
Insert Style
CC
Approach Angle
95 Degrees
ANSI Code
SCLCR083
Compatible Hardware
T15 Insert Screw
ISO Number
SCLCR083
Insert Holding Type
Screw On
Cutting Application
Facing, Profiling, Turning
Toolholder Style
SCLC
Coolant Fed
Non-Coolant Through
Side Cutting Edge Angle
-5 Degrees
Material - Machining
High Speed Steel
Lead Angle
-5 Degrees
Measurement System
Decimal Inch

Description

Indexable Turning Toolholder, SCLC, Insert Style CC, Overall Length 3-1/2 in
