Widia Indexable Toolholder, SCLC, SCLCR164D - main

Indexable Toolholder, SCLC,

  • Mfr # SCLCR164D

  • Zoro # G3790733

product price: $118.99
/ea
Free Shipping & Returns

Key Features

Number of Inserts Required
1
Insert Size
432
Overall Length
6 in
Shank Length
5-1/4 in
Clamp
Screw
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SCLCR164D
Zoro #
G3790733
UPC #
4021169422454
Country of Origin
Bulgaria

Dimensions

Insert Size
432
Overall Length
6 in
Shank Length
5-1/4 in
Cutting Length
0.5077"
Shank Width
1 in
Shank Height
1 in
Head Length
3/4 in

Details

Item
Indexable Turning Toolholder
Number of Inserts Required
1
Clamp
Screw
Insert Shape
80 Degrees Diamond
Style
Screw-On
Rake
Positive
Shank
Square
Insert Screw
T15
Cutting Direction
Right Hand
Material
Steel
ANSI Code
SCLCR164D
Cutting Application
Facing, Profiling, Turning
Side Cutting Edge Angle
-5 Degrees
Approach Angle
95 Degrees
Insert Style
CC
Toolholder Style
SCLC
Coolant Fed
Non-Coolant Through
Insert Clearance Angle
7 Degrees
ISO Number
SCLCR164D
Insert Inscribed Circle
1/2 in
Compatible Hardware
4.00mm Shim Screw, T15 Insert Screw
Insert Holding Type
Screw On
Material - Machining
High Speed Steel
Measurement System
Decimal Inch
Lead Angle
-5 Degrees

Description

Indexable Turning Toolholder, SCLC, Insert Style CC, Overall Length 6 in
