Widia Indexable Toolholder, SVVB, SVVBN163 - main

Indexable Toolholder, SVVB,

  • Mfr # SVVBN163

  • Zoro # G3787190

product price: $180.99
/ea
Free Shipping & Returns

Key Features

Cutting Length
0.6538"
Cutting Direction
Neutral
Insert Shape
35 Degrees Diamond
Rake
0 Degrees Axial, 0 Degrees Radial
Material
Steel
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
SVVBN163
Zoro #
G3787190
UPC #
4021169421846
Country of Origin
United States

Dimensions

Cutting Length
0.6538"
Insert Size
332
Overall Length
6 in
Shank Length
4-11/16 in
Head Length
1-5/16 in
Shank Height
1 in
Shank Width
1 in

Details

Item
Indexable Turning Toolholder
Cutting Direction
Neutral
Insert Shape
35 Degrees Diamond
Rake
0 Degrees Axial, 0 Degrees Radial
Material
Steel
Number of Inserts Required
1
Style
Screw-On
Insert Screw
T15
Shank
Square
Clamp
Screw
Insert Clearance Angle
5 Degrees
Toolholder Style
SVVB
Insert Inscribed Circle
3/8 in
Coolant Fed
Non-Coolant Through
Approach Angle
72.5 Degrees
ANSI Code
SVVBN163
ISO Number
SVVBN163
Compatible Hardware
M3.5 Shim Screw, T15 Insert Screw
Insert Holding Type
Screw On
Side Cutting Edge Angle
17.5 Degrees
Insert Style
VB
Cutting Application
Profiling, Turning
Material - Machining
High Speed Steel
Measurement System
Decimal Inch
Lead Angle
17.500 deg

Description

Indexable Turning Toolholder, SVVB, Insert Style VB, Overall Length 6 in
