  9. Milling Insert, Parallelogram, 11.68mm
Widia Milling Insert, Parallelogram, 11.68mm XDPT1106SRMM - main

Milling Insert, Parallelogram, 11.68mm

  • Mfr # XDPT1106SRMM

  • Zoro # G3801951

product price: $15.19
/ea
Sold in multiples of 5 for $75.95

Key Features

For Use With
VSM11 Series Shoulder Mills
Series
VSM11
Cutting Direction
Right Hand
Stainless (M) Compatibility
Yes
Insert Thickness
0.1580"
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
XDPT1106SRMM
Zoro #
G3801951
UPC #
4059782445529
Country of Origin
United States

Dimensions

Insert Thickness
0.1580"
Mounting Hole Dia.
3.00mm
Insert Size
110424
Thickness
0.1580 in
Width
6.94mm
Through Hole Inside Dia.
3.00mm
Cutting Edge Length
11.68mm
Corner Radius
2.40mm

Details

For Use With
VSM11 Series Shoulder Mills
Series
VSM11
Cutting Direction
Right Hand
Stainless (M) Compatibility
Yes
Hardened (H) Compatibility
Yes
Mounting Style
Taper Screw
Chip-Breaker
Yes
Rake
18 Degrees
Lead Angle
1 Degrees ANSI, 89 Degrees ISO
ISO Number
XDPT110424PDSRMM
Non Ferrous (N) Compatibility
Yes
Workpiece Compatibility
Cast Iron (K), Hardened (H), Nonferrous (N), Stainless (M), Steel (P), Super Alloy (S)
Cast Iron (K) Compatibility
Yes
Super Alloy (S) Compatibility
Yes
Insert Shape
Parallelogram
Insert Style
XDPT
Item
Parallelogram Milling Insert
Steel (P) Compatibility
Yes
Grade
WS40PM
Insert Material
Carbide
Number of Cutting Edges
2
Features
MM is a Medium to Heavy-Machining Geometry and is the First Choice for General Purpose and Universal Applications
Manufacturer Grade
WS40PM
Chip-Breaker Style
On One Side
Primary Material Application ISO Code
M, P, S
Secondary Material Application
Steel
Chip-Breaker Code
MM
For Toolholder
VHM11D100Z02W225XD11, VHM11D150Z05S250XD11, VHM11D200Z04S300XD11, VHM11D200Z06S300XD11, VSM11D150Z04S075XD11, VSM11D150Z06S075XD11, VSM11D200Z05S075XD11, VSM11D200Z08S075XD11, VSM11D250Z06S075XD11, VSM11D250Z09S075XD11, VSM11D300Z08S100XD11, VSM11D400Z09S150XD11
Shape
Parallelogram
Clearance Angle
15 Degrees
ANSI Code
XDPT1106SRMM
Finish - Machining
AlTiN
Measurement System
Metric
Material - Machining
Carbide
Hole Type
40 Degrees to 60 Degrees Countersink Hole
Insert Holding Type
Taper Screw
Included Angle
75 Degrees
Primary Material Application
Nickel, Stainless Steel, Steel, Titanium
Secondary Material Application ISO Code
P

Description

Parallelogram Milling Insert, 18 Degrees , XDPT1106SRMM, MM, On One Side, 15 Degrees
