Widia Modular Drill, 54.00mm Drill Depth TDMX170R3SL20M - main

Modular Drill, 54.00mm Drill Depth

  • Mfr # TDMX170R3SL20M

  • Zoro # G3821935

product price: $455.99
/ea
Free Shipping & Returns

Key Features

Diameter
20.00mm
ISO Number
TDMX170R3SL20M
Cutting Direction
Right Hand
Overall Length
136.00mm
Max. Dia.
17.9990mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TDMX170R3SL20M
Zoro #
G3821935
UPC #
4061779041683
Country of Origin
Germany

Dimensions

Diameter
20.00mm
Overall Length
136.00mm
Max. Dia.
17.9990mm
Body Length
50.00mm
Seat Size
B
Shank Dia.
20.00mm
Max. Drilling Depth
18.00mm
Min. Drill Dia.
17.00mm
Shank Dia. Measurement System
Metric
Flute Length
54.00mm
Shank Length
50.00mm
Depth x Dia. Ratio
3xD
Max. Drill Dia.
54.00mm

Description

Exchangeable Drill Tip, TDMX, Shank Type - Machining Round with Flat and Side Lock, High Speed Steel
