Shop WIDIA

Pipe Tap, 3/8"-19, Taper, 4 Flutes, G

  • Mfr # VTSFT8607

  • Zoro # G3929313

product price:
$
111.99
/ea
Free Shipping & Returns

Key Features

Tap Thread Size
3/8"-19
Tap Chamfer
Taper
Number of Flutes
4
Tap Thread Type
G
Tap Finish
Black Oxide
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
VTSFT8607
Zoro #
G3929313
UPC #
-
Country of Origin
United States

Dimensions

Tap Thread Size
3/8"-19
Shank Dia.
1/2"
Tap Dimension Type
Inch
Thread Length
9/16"
Pitch Diameter Limit
Not Rated
Overall Length
3-15/16"
Tap Size
3/8"
Thread Size
3/8"-19
Square Size
0.3540 in
Shank Length
2 3/32 in
Tap Length Standard
DIN 5156, DIN EN ISO 228, USCTI
Square Width
0.35 in
Shank Diameter
15/32 in
Square Length
0.35 in
Wire Rope Length
3 15/16 in
Length
3 15/16 in

Details

Item
Pipe Tap
Tap Chamfer
Taper
Number of Flutes
4
Tap Thread Type
G
Tap Finish
Black Oxide
Number of Pieces
1
List Number
VT-SFT
Tap Style
Pipe
Tap Material
Carbide
Standards
DIN 5156, DIN EN ISO 228, USCTI
Thread Direction
Right Hand
Cutting Direction - Machining
Right Hand
Series
VTSFT
Coolant Fed
Non-Coolant Through
Thread Standard
BSPP
Spiral Direction
Right Hand
Threads per Inch
19
Primary Material Application
Steel
Primary Material Application ISO Code
P
Tap Shank Standard
DIN 5156, DIN EN ISO 228, USCTI
Extended Neck
Yes
Helix Angle
42 Degrees
Measurement System
Fractional Inch
Interrupted Thread
No
Material Grade - Machining
WP49EG
Secondary Material Application ISO Code
K, M, N
Secondary Material Application
Aluminum, Brass, Bronze, Cast Iron, Copper, Stainless Steel
Tap Application
Through Hole
Shank Type
Square
Flute Type
Spiral

Description

Pipe and Conduit Thread Tap, Thread Size 3/8 In.-19, BSPP, Overall Length 3 15/16 in, Carbide, Black Oxide, Right Hand, Thread Length 19/32 in, Thread Limit Not Applicable, Class of Fit Not Applicable, Number of Flutes 4
