  11. Spiral Point Tap, #5-40, Plug, UNC, 2 Flutes, Uncoated
Widia Spiral Point Tap, #5-40, Plug, UNC, 2 Flutes, Uncoated 13225 - main

Spiral Point Tap, #5-40, Plug, UNC, 2 Flutes, Uncoated

  • Mfr # 13225

  • Zoro # G1855016

product price: $12.89
/ea

Key Features

Shank Dia.
0.141"
Tap Material
High Speed Steel
Tap Dimension Type
Inch
Tap Chamfer
Plug
Tap Size
#5
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
13225
Zoro #
G1855016
UPC #
-
Country of Origin
Multiple

Dimensions

Shank Dia.
0.141"
Tap Dimension Type
Inch
Tap Size
#5
Overall Length
1-15/16"
Pitch Diameter Limit
H2
Tap Thread Size
#5-40
Thread Length
5/8"
75% Thread Drill Size
#39
65% Thread Drill Size
#37
55% Thread Drill Size
#36
Square Size
0.1100 in
Thread Size
#5-40
Shank Length
1 9/32 in
Size
#5

Details

Item
Spiral Point Tap
Tap Material
High Speed Steel
Tap Chamfer
Plug
Tap Style
Spiral Point
Number of Flutes
2
Number of Pieces
1
Tap Grouping
Tap
Standards
ANSI
List Number
5301
Tap Finish
Uncoated
Tap Thread Type
UNC
Thread Direction
Right Hand
Cutting Direction - Machining
Right Hand
Secondary Material Application
Aluminum, Brass, Bronze, Cast Iron, Copper, Stainless Steel, Steel
Primary Material Application
Steel
Thread Limit
H2
Primary Material Application ISO Code
P
Extended Neck
No
Measurement System
Pipe
Secondary Material Application ISO Code
K, M, N
Series
5301/2301
Thread Standard
UNC, UNJC
Threads per Inch
40
Shank Type - Machining
Straight
Coolant Fed
Non-Coolant Through
Spiral Direction
Neutral
Class of Fit
H3
Helix Angle
0 Degrees

Description

Spiral Point Tap, Thread Size #5-40, UNC, Overall Length 1 15/16 in, High Speed Steel, Bright (Uncoated), Right Hand, Thread Length 5/8 in, 75 Percent Thread Drill Size #39, Thread Limit H2, Class of Fit H3, Number of Flutes 2
