  11. Thread Forming Tap, #0-80, Bottoming, Bright, 3 Flutes
Widia Thread Forming Tap, #0-80, Bottoming, Bright, 3 Flutes 17200 - main

Thread Forming Tap, #0-80, Bottoming, Bright, 3 Flutes

  • Mfr # 17200

  • Zoro # G7695871

product price: $23.19
/ea

Key Features

Tap Thread Size
#0-80
Tap Chamfer
Bottoming
Tap Finish
Bright
Number of Flutes
3
Number of Pieces
1
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
17200
Zoro #
G7695871
UPC #
-
Country of Origin
Korea, Republic of

Dimensions

Tap Thread Size
#0-80
Overall Length
1-5/8"
Thread Length
5/16"
Tap Dimension Type
Inch
Pitch Diameter Limit
H2
Shank Dia.
0.4724mm
Tap Size
#0
55% Thread Drill Size
1.40 mm
Shank Length
1 5/16 in
Thread Size
#0-80
65% Thread Drill Size
1.38 mm
75% Thread Drill Size
1.36 mm
Square Size
0.1100 in

Details

Item
Thread Forming Tap
Tap Chamfer
Bottoming
Tap Finish
Bright
Number of Flutes
3
Number of Pieces
1
List Number
2502/5502
Tap Style
Thread Forming
Tap Thread Type
UNC
Tap Material
High Speed Steel
Tap Grouping
Tap
Thread Direction
Right Hand
Standards
DIN 376
Cutting Direction - Machining
Right Hand
Secondary Material Application
Aluminum, Brass, Bronze, Cast Iron, Copper, Stainless Steel
Threads per Inch
80
Thread Limit
H2
Spiral Direction
Neutral
Primary Material Application ISO Code
P
Coolant Fed
Non-Coolant Through
Features
Blind Holes, Bottoming Entry Taper, Forming Taps
Secondary Material Application ISO Code
K, M, N
Material Grade - Machining
5502
Primary Material Application
Steel
Thread Standard
UNF
Series
2502/5502
Extended Neck
No
Measurement System
Decimal Inch
Helix Angle
0 Degrees

Description

Thread Forming Tap, Thread Size #0-80, UNF, Overall Length 1.63 in, High Speed Steel, Bright (Uncoated), Right Hand, Thread Length 0.31 in, 75 Percent Thread Drill Size 1.36 mm, Thread Limit H2, Class of Fit Not Applicable
