Thread Turning Toolholder, A-DCL-KC, HSS
Mfr # A32SDCLNL12KC04
Zoro # G3820492
product price: $409.99
/ea
Free Shipping & Returns
Key Features
Insert Size
120408
Cutting Direction
Left Hand
ISO Number
A32SDCLNL12KC04
Rake
-12 Degrees Radial, -5 Degrees Axial
Shank Dia.
32.00mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
A32SDCLNL12KC04
Zoro #
G3820492
UPC #
4050841467568
Country of Origin
India
Dimensions
Insert Size
120408
Shank Dia.
32.00mm
Cutting Dia.
1.2600mm
Overall Length
250.00mm
Shank Length
206.55mm
Min. Bore Dia.
40.00mm
Insert Cutting Edge Length
12.90mm
Details
Item
Indexable Thread Turning Tool Holder
Cutting Direction
Left Hand
ISO Number
A32SDCLNL12KC04
Rake
-12 Degrees Radial, -5 Degrees Axial
Coolant Fed
Coolant Through
Center to Cutting Tip
0 in
Shank Material
High Speed Steel
Insert Holding Type
Top Clamping
Toolholder Style
A-DCL-KC
Cutting Application
Inside Diameter Internal Threading
ANSI Code
A32SDCLNL12KC04
Insert Style
CN.120408
Number of Coolant Holes
1
Measurement System
Metric
Description
Indexable Thread Turning Tool Holder, Insert Style CN.120408, Left Hand, Inside Diameter Internal Threading, ANSI Code A32SDCLNL12KC04, Center to Cutting Tip 0 in, Coolant Fed Coolant Through
