Thread Turning Toolholder, A16RCTFPR11
Mfr # A16RCTFPR11
Zoro # G3759942
product price: $148.99
/ea
Free Shipping & Returns
Key Features
Rake
-4 Degrees Radial, 5 Degrees Axial
Shank Length
6-3/4 in
Shank Shape
Offset
Cutting Direction
Right Hand
Overall Length
200.00mm
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
A16RCTFPR11
Zoro #
G3759942
UPC #
4021169802003
Country of Origin
United States
Dimensions
Shank Length
6-3/4 in
Overall Length
200.00mm
Shank Dia.
16.00mm
Insert Size
110304
Cutting Dia.
0.6299mm
Min. Bore Dia.
20.00mm
Insert Cutting Edge Length
11.00mm
Details
Item
Indexable Thread Turning Tool Holder
Rake
-4 Degrees Radial, 5 Degrees Axial
Shank Shape
Offset
Cutting Direction
Right Hand
Coolant Fed
Coolant Through
Cutting Application
Inside Diameter Chamfering and Profiling
Toolholder Style
A-CTFP
Shank Material
High Speed Steel
Number of Coolant Holes
1
Insert Style
TP..
ANSI Code
A16RCTFPR11
ISO Number
A16RCTFPR11
Center to Cutting Tip
0.19mm
Insert Holding Type
Top Clamping
Measurement System
Metric
Description
Indexable Thread Turning Tool Holder, Insert Style TP.., Right Hand, Inside Diameter Chamfering and Profiling, ANSI Code A16RCTFPR11, Center to Cutting Tip 0.19mm, Coolant Fed Coolant Through
