Thread Turning Toolholder, NEL204D
Mfr # NEL204D
Zoro # G3748779
product price: $179.99
/ea
Free Shipping & Returns
Key Features
Shank Shape
Square
Cutting Direction
Left Hand
Overall Length
6 in
Rake
0 Degrees Axial, 0 Degrees Radial
Insert Size
4
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
NEL204D
Zoro #
G3748779
UPC #
4021169662560
Country of Origin
United States
Dimensions
Overall Length
6 in
Insert Size
4
Shank Length
5-1/4"
Shank Height
1-1/4 in
Shank Width
1-1/4 in
Depth of Cut
0.2940"
Max. Bore Depth
2"
Head Length
19.05mm
Min. Bore Dia.
3"
Details
Item
Indexable Thread Turning Tool Holder
Shank Shape
Square
Cutting Direction
Left Hand
Rake
0 Degrees Axial, 0 Degrees Radial
Insert Style
N.4R
Cutting Application
Threading
Shank Material
High Speed Steel
Coolant Fed
Non-Coolant Through
Center to Cutting Tip
1-1/4"
ISO Number
NEL204D
Insert Holding Type
Top Clamping
ANSI Code
NEL204D
Toolholder Style
NE
Measurement System
Fractional Inch
Description
Indexable Thread Turning Tool Holder, Cutting Direction Left Hand, Rake 0 Degrees Axial, 0 Degrees Radial, Shank Width 1-1/4 in, Shank Height 1-1/4 in, Overall Length 6 in
