Thread Turning Toolholder, NSR2525M2
Mfr # NSR2525M2
Zoro # G3762173
product price: $151.99
/ea
Free Shipping & Returns
Key Features
Shank Shape
Square
Rake
0 Degrees Axial, 0 Degrees Radial
Overall Length
150.00mm
Shank Length
132.25mm
Insert Size
2
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
NSR2525M2
Zoro #
G3762173
UPC #
4021169661433
Country of Origin
Brazil
Dimensions
Overall Length
150.00mm
Shank Length
132.25mm
Insert Size
2
Shank Height
25.00mm
Shank Width
63/64 in
Depth of Cut
3.51mm
Head Length
19.00mm
Details
Item
Indexable Thread Turning Tool Holder
Shank Shape
Square
Rake
0 Degrees Axial, 0 Degrees Radial
Cutting Direction
Right Hand
Shank Material
High Speed Steel
Cutting Application
Face Grooving, Grooving
Insert Style
N.2R
Coolant Fed
Non-Coolant Through
ISO Number
NSR2525M2
Center to Cutting Tip
38.10mm
ANSI Code
NSR2525M2
Insert Holding Type
Top Clamping
Toolholder Style
NS
Measurement System
Metric
Description
Indexable Thread Turning Tool Holder, Cutting Direction Right Hand, Rake 0 Degrees Axial, 0 Degrees Radial, Shank Width 63/64 in, Shank Height 25.00mm, Overall Length 150.00mm
