Thread Turning Toolholder, NSR2525M4
Mfr # NSR2525M4
Zoro # G3762645
product price: $131.99
/ea
Free Shipping & Returns
Key Features
Cutting Direction
Right Hand
Rake
0 Degrees Axial, 0 Degrees Radial
Shank Length
116.25mm
Overall Length
150.00mm
Insert Size
4
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
NSR2525M4
Zoro #
G3762645
UPC #
4021169726422
Country of Origin
United States
Dimensions
Shank Length
116.25mm
Overall Length
150.00mm
Insert Size
4
Shank Height
25.00mm
Shank Width
63/64 in
Depth of Cut
7.47mm
Head Length
35.00mm
Details
Item
Indexable Thread Turning Tool Holder
Cutting Direction
Right Hand
Rake
0 Degrees Axial, 0 Degrees Radial
Shank Shape
Square
Coolant Fed
Non-Coolant Through
Shank Material
High Speed Steel
Cutting Application
Face Grooving, Grooving
Insert Style
N.4R
Insert Holding Type
Top Clamping
ANSI Code
NSR2525M4
Toolholder Style
NS
ISO Number
NSR2525M4
Center to Cutting Tip
38.10mm
Measurement System
Metric
Description
Indexable Thread Turning Tool Holder, Cutting Direction Right Hand, Rake 0 Degrees Axial, 0 Degrees Radial, Shank Width 63/64 in, Shank Height 25.00mm, Overall Length 150.00mm
