Thread Turning Toolholder, WGCSM, HSS
Mfr # WGCSMR2525M0216
Zoro # G3749004
product price: $190.99
/ea
Free Shipping & Returns
Key Features
Overall Length
150.00mm
Shank Shape
Square
Insert Size
2
Rake
3 Degrees Axial
Cutting Direction
Right Hand
Get a 10% off coupon
Free 30-day returns
Return PolicyGet 30 days to pay with Net 30
Apply NowReal support from real people
Contact our U.S. based teamSpecifications
Product Information
MFR #
WGCSMR2525M0216
Zoro #
G3749004
UPC #
4059782533820
Country of Origin
Brazil
Dimensions
Overall Length
150.00mm
Insert Size
2
Shank Length
119.00mm
Shank Height
25.00mm
Depth of Cut
16.00mm
Head Length
31.00mm
Shank Width
25.00mm
Cutting Height
25.00mm
Details
Item
Indexable Thread Turning Tool Holder
Shank Shape
Square
Rake
3 Degrees Axial
Cutting Direction
Right Hand
Insert Holding Type
Clamp
ANSI Code
WGCSMR2525M0216
Toolholder Style
WGCSM
Center to Cutting Tip
25.00mm
Insert Style
WG0200M02P02
ISO Number
WGCSMR2525M0216
Shank Material
High Speed Steel
Coolant Fed
Non-Coolant Through
Cutting Application
Chamfering, Cut-Off, Facing, Grooving, Outside Diameter Deep Grooving, Profiling, Turning
Measurement System
Metric
Description
Indexable Thread Turning Tool Holder, Insert Style WG0200M02P02, Right Hand, Chamfering, Cut-Off, Facing, Grooving, Outside Diameter Deep Grooving, Profiling, Turning, Shank Width 25.00mm, ANSI Code WGCSMR2525M0216, Center to Cutting Tip 25.00mm, Coolant Fed Non-Coolant Through
