Widia Threading Insert, CDT, Triangle CDT50022R - main

Threading Insert, CDT, Triangle

  • Mfr # CDT50022R

  • Zoro # G3876273

product price: $44.49
/ea
Sold in multiples of 5 for $222.45

Key Features

Insert Size
5
Grade
CG5
Cutting Direction
Right Hand
Inscribed Circle
5/32 in
Insert Type
CDT
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CDT50022R
Zoro #
G3876273
UPC #
4021169354083
Country of Origin
United States

Dimensions

Insert Size
5
Corner Radius
0.05mm
Thread Height Difference
0.76mm
Thickness
1.27mm

Details

Item
Threading Insert
Grade
CG5
Cutting Direction
Right Hand
Inscribed Circle
5/32 in
Insert Type
CDT
Insert Shape
Triangle
ISO Number
CDT50022R
Manufacturer Grade
CG5
Secondary Material Application ISO Code
K
Measurement System
Metric
Material Grade - Machining
Submicron
Clearance Angle
25 Degrees
Number of Cutting Edges
2
Min. Thread per Inch
24
Primary Material Application
Aluminum, Brass, Bronze, Copper, Nickel, Stainless Steel, Steel, Titanium
Thread Direction
Right Hand
Secondary Material Application
Cast Iron
Feed Type
High
Thread Pitch
0.50mm
Primary Material Application ISO Code
M, N, P, S
Insert Style
CDT
Coating Process
PVD
Cutting Application
Turning
ANSI Code
CDT50022R
Insert Holding Type
5/32 in
Max. Thread Pitch
48
Finish - Machining
TiN
Threading Location
External, Internal
Material - Machining
Carbide
Included Angle
60 Degrees

Description

Threading Insert, CDT, External, Internal, Cutting Direction Right Hand, Primary Material Application Aluminum, Brass, Bronze, Copper, Nickel, Stainless Steel, Steel, Titanium, Inscribed Circle 5/32 in
