Widia Threading Insert, CPT, Triangle CPT20052R - main

Threading Insert, CPT, Triangle

  • Mfr # CPT20052R

  • Zoro # G3875740

product price: $47.49
/ea
Sold in multiples of 10 for $474.90

Key Features

Insert Size
2
Grade
CG5
Cutting Direction
Right Hand
Inscribed Circle
1/4 in
ISO Number
CPT20052R
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
CPT20052R
Zoro #
G3875740
UPC #
4021169379543
Country of Origin
United States

Dimensions

Insert Size
2
Thread Height Difference
1.65mm
Corner Radius
0.13mm
Thickness
1.91mm

Details

Item
Threading Insert
Grade
CG5
Cutting Direction
Right Hand
Inscribed Circle
1/4 in
ISO Number
CPT20052R
Insert Shape
Triangle
Insert Type
CPT
Material Grade - Machining
Submicron
Measurement System
Metric
Secondary Material Application ISO Code
K
Min. Thread per Inch
10
Insert Holding Type
1/4 in
Insert Style
CPT
Material - Machining
Carbide
Primary Material Application ISO Code
M, N, P, S
Secondary Material Application
Cast Iron
Threading Location
External, Internal
Clearance Angle
11 Degrees
Number of Cutting Edges
2
Manufacturer Grade
CG5
Cutting Application
Turning
Coating Process
PVD
Included Angle
60 Degrees
Max. Thread Pitch
24
Finish - Machining
TiN
Primary Material Application
Aluminum, Brass, Bronze, Copper, Nickel, Stainless Steel, Steel, Titanium
Thread Direction
Right Hand
Feed Type
High
Thread Pitch
1.00mm
ANSI Code
CPT20052R

Description

Threading Insert, CPT, External, Internal, Cutting Direction Right Hand, Primary Material Application Aluminum, Brass, Bronze, Copper, Nickel, Stainless Steel, Steel, Titanium, Inscribed Circle 1/4 in
