  5. Low Pressure Gauge, 0 to 100 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location
Winters Low Pressure Gauge, 0 to 100 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location PLP343 - main
Shop WINTERS

Low Pressure Gauge, 0 to 100 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location

  • Mfr # PLP343

  • Zoro # G6756043

product price:  $46.75
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PLP343
Zoro #
G6756043
UPC #
628311203073
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Manufacturer Warranty Length
5 yr
Case Depth
1.9 in
Case Diameter
2.625 in
Nominal Dial Size
2 1/2 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Low Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Type
NPT
Application
Air Compressors, Air Filters, Regulators and Respirators, Vacuum Applications
Gauge Case Material
Steel
Series
PLP
Lens Material
Polycarbonate
Primary Pressure Range
0 to 100
Primary Scale Units
in wc
IP/NEMA Rating
IP52
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Case Color
Black
Gauge Special Options
Diaphragm
Calibration Certificate Included
No
For Use With
Air Compressors, Air Filters, Gas Burners, Respirators, Suction Regulators, Vacuum Ovens, Vacuum Pumps
Gauge Primary Range Numbered Graduations
10/10
Case Material
Steel
Gauge Primary Range Smallest Graduation
5 in-oz
Smallest Graduation
4 in wc/2 in-oz
Socket Material
Brass
Gauge Application
For Natural Gas & Other Gases
Gauge Secondary Range Values
0 to 70,000
Characteristics
Suitable for Corrosive and Non Corrosive Gaseous Media, Natural Gas and Propane Pressure, Air Flow Indication, Leak Detection
Standards
CRN Registered
Connection Type
MNPT
Adjustable Pointer
No
Includes Mounting Hardware
No
Pointer Color
Black
Dial Color
White
Bezel Mounting Type
No Bezel
Secondary Scale Units
oz/in2
Process Temperature Range
-40 Degrees to 150 Degrees F
Over-Pressure Limit
30% of Full Scale
Includes Calibration Certificate
No
Pointer Characteristics
Aluminum, Anodized Black
Case Finish
Painted
Sensor Material
Phosphor Bronze
Sensor Type
Diaphragm
Freeze Resistant Movement
No
Pressure Range Type
Vacuum
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Cleaned for Oxygen Service
No
Gauge Case Liquid
None
Includes Vent Plug
No
Primary Scale Minor Graduations
5
Dial Face Material
Aluminum
Field Fillable
No
Pressure Gauge Type
Low Pressure Gauge
Accuracy Scale
Mid-Scale
Pointer Material
Aluminum
Dry Dampening Feature
None
Accuracy Grade
ASME B40.100 Grade B
Removable Bezel
No
Secondary Pressure Range
0 to 58
Primary Scale Numeric Increments
10
Scale Type
Dual
Compatible Process Media
Gaseous
Vibration Resistance
None
Process Connection Gender
Male
Operating Temperature Range
-40 Degrees to 150 Degrees F
Primary Scale Pressure Measurement - Minimum
0 in wc
Process Media Temperature - Minimum
-40 Degrees F
Operating Temperature - Maximum
150 Degrees F
Operating Temperature - Minimum
-40 Degrees F
Compatible with Brand
Universal
Secondary Scale Pressure Measurement - Maximum
58 oz/sq in
Primary Scale Pressure Measurement - Maximum
100 in wc
Case Liquid
None
Secondary Scale Pressure Measurement - Minimum
0 oz/sq in
IP Rating
IP52
NEMA Enclosure Rating
5
Process Media Temperature - Maximum
150 Degrees F

Description

Low Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Center Back, Case Color Black, IP/NEMA Rating IP52, Primary Pressure Range 0 to 100, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Low Pressure Gauge, Liquid-Filled Case No
