Winters Low Pressure Gauge, 0 to 15 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material PLP300 - main
Shop WINTERS

Low Pressure Gauge, 0 to 15 psi, 2 1/2 in Dial, 1/4 in NPT, Bottom Location, Steel Case Material

  • Mfr # PLP300

  • Zoro # G1937249

product price:  $35.19
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PLP300
Zoro #
G1937249
UPC #
628311203158
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Nominal Dial Size
2 1/2 in
Case Depth
1.9 in
Manufacturer Warranty Length
5 yr
Case Diameter
2.625 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Low Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Bottom
Process Connection Type
NPT
Application
Air Compressors, Air Filters, Regulators and Respirators, Vacuum Applications
Gauge Case Material
Steel
Series
PLP
Lens Material
Polycarbonate
Primary Pressure Range
0 to 15
Primary Scale Units
in wc
IP/NEMA Rating
IP52
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Gauge Special Options
Diaphragm
Smallest Graduation
0.1 in wc/0.2 in-oz
Case Color
Black
Gauge Secondary Range Values
0 to 70,000
Gauge Primary Range Numbered Graduations
2/1
For Use With
Air Compressors, Air Filters, Gas Burners, Respirators, Suction Regulators, Vacuum Ovens, Vacuum Pumps
Calibration Certificate Included
No
Gauge Primary Range Smallest Graduation
1 in wc
Characteristics
Suitable for Corrosive and Non Corrosive Gaseous Media, Natural Gas and Propane Pressure, Air Flow Indication, Leak Detection
Gauge Application
For Natural Gas & Other Gases
Socket Material
Brass
Case Material
Steel
Standards
CRN Registered
Connection Type
MNPT
Secondary Scale Units
oz/in2
Dry Dampening Feature
None
Includes Calibration Certificate
No
Dial Color
White
Cleaned for Oxygen Service
No
Over-Pressure Limit
30% of Full Scale
Pointer Color
Black
Vibration Resistance
None
Field Fillable
No
Freeze Resistant Movement
No
Includes Mounting Hardware
No
Sensor Material
Phosphor Bronze
Dial Face Material
Aluminum
Case Finish
Painted
Pointer Characteristics
Aluminum, Anodized Black
Primary Scale Minor Graduations
1
Scale Type
Dual
Accuracy Grade
ASME B40.100 Grade B
Includes Vent Plug
No
Accuracy Scale
Mid-Scale
Gauge Case Liquid
None
Secondary Pressure Range
0 to 9
Pointer Material
Aluminum
Adjustable Pointer
No
Primary Scale Numeric Increments
1, 2
Process Connection Gender
Male
Removable Bezel
No
Process Temperature Range
-40 Degrees to 150 Degrees F
Sensor Type
Diaphragm
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
Compatible Process Media
Gaseous
Pressure Gauge Type
Low Pressure Gauge
Bezel Mounting Type
No Bezel
Pressure Range Type
Pressure
Operating Temperature Range
-40 Degrees to 150 Degrees F
IP Rating
IP52
Primary Scale Pressure Measurement - Maximum
15 in wc
Process Media Temperature - Maximum
150 Degrees F
Case Liquid
None
Primary Scale Pressure Measurement - Minimum
0 in wc
Operating Temperature - Maximum
150 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 oz/sq in
Operating Temperature - Minimum
-40 Degrees F
NEMA Enclosure Rating
5
Process Media Temperature - Minimum
-40 Degrees F
Secondary Scale Pressure Measurement - Maximum
9 oz/sq in
Compatible with Brand
Universal

Description

Low Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating IP52, Primary Pressure Range 0 to 15, Dry Dampening Feature None, Vibration Resistance None, Dial Color White, Pressure Gauge Type Low Pressure Gauge, Liquid-Filled Case No
