Winters Panel-Mount Pressure Gauge, 0 to 200 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location PFQ906-DRY-25FF - main

Panel-Mount Pressure Gauge, 0 to 200 psi, 2 1/2 in Dial, 1/4 in NPT, Center Back Location

  • Mfr # PFQ906-DRY-25FF

  • Zoro # G1936853

product price:  $16.35
/ea

Key Features

Accuracy
+/-1.5%
Process Connection Location
Center Back
Process Connection Size
1/4 in
Process Connection Type
NPT
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PFQ906-DRY-25FF
Zoro #
G1936853
UPC #
-
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 1/2 in
Nominal Dial Size
2 1/2 in
Bolt Circle Diameter
2.898 in
Flange Diameter
2.5 in
Case Diameter
2.445 in
Manufacturer Warranty Length
5 yr
Case Depth
0.772 in
Nominal Dial Diameter
2 1/2 in

Details

Item
Panel-Mount Pressure Gauge
Accuracy
+/-1.5%
Process Connection Location
Center Back
Process Connection Type
NPT
Application
Compressors, Hydraulics, Machinery, Motors, Pneumatics, Pumps
Gauge Case Material
304 Stainless Steel
Series
PFQ
Lens Material
Polycarbonate
Primary Pressure Range
0 to 200
Primary Scale Units
psi
IP/NEMA Rating
IP65
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
Yes
Blowout Safety Back
No
Smallest Graduation
2 psi/20 kPa
Calibration Certificate Included
No
Case Color
Metallic
Gauge Primary Range Numbered Graduations
50/200
Gauge Special Options
Heavy Duty
Gauge Primary Range Smallest Graduation
10/100
Gauge Secondary Range Values
0 to 1380
For Use With
Media Compatible with Bronze
Features
Ring Terminal
Case Material
304 Stainless Steel
Socket Material
Brass
Connection Type
MNPT
Standards
ASME, CRN
Pressure Range Type
Pressure
Includes Mounting Hardware
No
Case Construction
Welded Joint
Removable Bezel
Yes
Process Connection Gender
Male
Gauge Case Liquid
None
Scale Type
Dual
Includes Vent Plug
Yes
Pointer Color
Black
Pointer Material
Aluminum
Sensor Type
Bourdon Tube
Secondary Pressure Range
0 to 1,400
Bezel Mounting Type
Crimped
Pressure Gauge Type
Industrial Pressure Gauge
Ambient Operating Temperature Range
-40 Degrees to 200 Degrees F (-40 Degrees to 93 Degrees C)
Cleaned for Oxygen Service
No
Compatible Process Media
Air, Water
Dial Face Material
Aluminum
Field Fillable
Yes
Dry Dampening Feature
None
Bezel Gasket Material
Silicone
Bezel Material
304 Stainless Steel
Secondary Scale Units
kPa
Dial Color
White
Freeze Resistant Movement
No
Panel Mount Characteristics
3 0.197 in Dia Holes on 2.898 in Dia Bolt Circle
Vibration Resistance
Field-Fillable
Accuracy Scale
Full Scale
Non-Sparking
No
Movement Material
Brass OT59
Includes Calibration Certificate
No
Over-Pressure Limit
25%
Process Temperature Range
-40 Degrees to 200 Degrees F
Sensor Material
Phosphor Bronze
Operating Temperature Range
-40 Degrees to 200 Degrees F
Process Media Temperature - Maximum
200 Degrees F
Secondary Scale Pressure Measurement - Maximum
1,400 kPa
Case Liquid
None
Operating Temperature - Maximum
200 Degrees F
Secondary Scale Pressure Measurement - Minimum
0 kPa
NEMA Enclosure Rating
4
IP Rating
IP65
Compatible with Brand
Universal
Primary Scale Pressure Measurement - Minimum
0 psi
Process Media Temperature - Minimum
-40 Degrees F
Primary Scale Pressure Measurement - Maximum
200 psi
Operating Temperature - Minimum
-40 Degrees F

Description

Panel-Mount Pressure Gauge, Nominal Dial Size 2 1/2 in, Accuracy +/-1.5 Percent, Gauge Case Material 304 Stainless Steel, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable Yes, Process Connection Location Center Back, Case Color Metallic, IP/NEMA Rating IP65, Primary Pressure Range 0 to 200, Dry Dampening Feature None, Vibration Resistance Field-Fillable, Dial Color White
