  5. Pressure Gauge, 0 to 100 psi, 2 1/2 in Dial, 1 1/2 in Tri-Clamp, Bottom Location
Winters Pressure Gauge, 0 to 100 psi, 2 1/2 in Dial, 1 1/2 in Tri-Clamp, Bottom Location PSQ15804 - main

Pressure Gauge, 0 to 100 psi, 2 1/2 in Dial, 1 1/2 in Tri-Clamp, Bottom Location

  • Mfr # PSQ15804

  • Zoro # G1605613

product price:  $126.99
/ea
Free Shipping & Returns

Key Features

Accuracy
+/-1.50%
Process Connection Location
Bottom
Process Connection Size
1 1/2 in
Process Connection Type
Tri-Clamp
Dial Size (In.)
2 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
PSQ15804
Zoro #
G1605613
UPC #
628311263084
Country of Origin
China

Dimensions

Process Connection Size
1 1/2 in
Dial Size (In.)
2 1/2 in
Manufacturer Warranty Length
5 yr
Nominal Dial Size
2 1/2 in
Case Diameter
63.6 mm
Case Depth
32.4 mm
Nominal Dial Diameter
2 1/2 in

Details

Item
Pressure Gauge
Accuracy
+/-1.50%
Process Connection Location
Bottom
Process Connection Type
Tri-Clamp
Application
Beverage
Gauge Case Material
304 Stainless Steel
Series
PSQ
Lens Material
Polycarbonate
Primary Pressure Range
0 to 100
Primary Scale Units
psi
IP/NEMA Rating
IP65, NEMA 4X
Liquid-Filled Case
Yes
Hazardous Location Rating
Not Rated
Blowout Safety Back
No
Standards
3A 74-06 Certified, CRN Registered, RoHS
Gauge Primary Range Numbered Graduations
20/100
Case Color
Metallic
Calibration Certificate Included
No
Socket Material
316 Stainless Steel
Case Material
304 Stainless Steel
Gauge Filled With
Glycerin
Gauge Secondary Range Values
0 to 7
Features
3-A Dairy Approved Materials, Electro Polished Finish
Gauge Special Options
Heavy Duty
Smallest Graduation
2 psi/10 kPa
Connection Type
Triclamp
Gauge Primary Range Smallest Graduation
10/50
For Use With
Media Compatible with 316L Stainless Steel
Primary Scale Numeric Increments
20, 100
Primary Scale Minor Graduations
10, 50
Includes Vent Plug
No
Secondary Pressure Range
0 to 7
Sensor Material
316L Stainless Steel
Dry Dampening Feature
None
Process Temperature Range
0 Degrees to 250 Degrees F
Includes Calibration Certificate
No
Case Finish
Polished
Vibration Resistance
Liquid-Filled
Dial Face Material
Aluminum
Gauge Case Liquid
Glycerin
Over-Pressure Limit
25%
Secondary Pressure Scale Color
Red
Secondary Scale Units
bar
Dial Color
White
Compatible Process Media
Air, Beverage, Dairy, Food, Gas, Liquid, Pasty or Powdery Media
Pointer Characteristics
Adjustable Micrometer Pointer
Bezel Material
304 Stainless Steel
Movement Material
304 Stainless Steel
Freeze Resistant Movement
No
Field Fillable
Yes
Pressure Range Type
Pressure
Pressure Gauge Type
Sanitary Pressure Gauge
Cleaned for Oxygen Service
No
Removable Bezel
No
Adjustable Pointer
Adjustable Micrometer Pointer
Ambient Operating Temperature Range
40 Degrees to 150 Degrees F
Sensor Type
Bourdon Tube
Operating Temperature Range
40 Degrees to 150 Degrees F
IP Rating
IP65
Operating Temperature - Minimum
40 Degrees F
Process Media Temperature - Maximum
250 Degrees F
Primary Scale Vacuum Measurement - Minimum
0 psi
Operating Temperature - Maximum
150 Degrees F
Primary Scale Pressure Measurement - Minimum
0 psi
Resistance Properties
Corrosion Resistant, Dust Resistant, Water Resistant
NEMA Enclosure Rating
4X
Case Liquid
Glycerin
Primary Scale Pressure Measurement - Maximum
100 psi
Primary Scale Vacuum Measurement - Maximum
100 psi
Secondary Scale Pressure Measurement - Minimum
0 bar
Secondary Scale Pressure Measurement - Maximum
7 bar
Secondary Scale Color
Red
Process Media Temperature - Minimum
0 Degrees F

Description

Pressure Gauge,2-1/2" Dial Size,Silver
