Pressure Gauge, 0 to 300 psi, 4 1/2 in Dial, 1/4 in NPT Bottom Location

  • Mfr # PCT326LF

  • Zoro # G6163586

product price:
$
27.39
/ea

Key Features

Accuracy
+/-1.0%
Process Connection Location
Bottom
Process Connection Size
1/4 in NPT
Dial Size (In.)
4 1/2 in
Gauge Case Material
304 Stainless Steel
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
PCT326LF
Zoro #
G6163586
UPC #
628311250138
Country of Origin
China

Dimensions

Process Connection Size
1/4 in NPT
Dial Size (In.)
4 1/2 in
Case Diameter
5.9 in
Nominal Dial Size
4 1/2 in
Manufacturer Warranty Length
5 yr

Details

Item
Pressure Gauge
Accuracy
+/-1.0%
Process Connection Location
Bottom
Gauge Case Material
304 Stainless Steel
Series
PCT-LF
Lens Material
Acrylic
Primary Pressure Range
0 to 300
Primary Scale Units
psi
Liquid-Filled Case
No
Panel-Mountable
No
Calibration Certificate Included
No
Gauge Application
Most Commercial Air, Water and Steam Services (with Syphon)
Case Color
Silver
Characteristics
CRN Registered, Zero Adjustment Screw
Gauge Special Options
Zero Adjustment Screw
For Use With
Most Commercial Air, Water, and Steam Services That Require A 1% Full-Scale Accuracy
Pressure Range
0 to 300 psi/kPa
Socket Material
Brass
Case Material
304 Stainless Steel
NSF Certified
Yes
Wetted Materials
Brass / Bronze
Standards
CRN Registered
Connection Type
MNPT
Pressure Range Type
Pressure Gauge
Sensor Material
Bronze
Maximum Pressure
300
Operating Temperature Range
-40 Degrees to 200 Degrees F

Description

Pressure Gauge, Accuracy +/-1.0 Percent, Gauge Case Material 304 Stainless Steel, Lens Material Acrylic, Socket Material Brass
