  11. Pressure Gauge, 0 to 80 psi, 1/4 in MNPT, Plastic, Black
Winters Pressure Gauge, 0 to 80 psi, 1/4 in MNPT, Plastic, Black PFE3932R1 - main

Pressure Gauge, 0 to 80 psi, 1/4 in MNPT, Plastic, Black

  • Mfr # PFE3932R1

  • Zoro # G0405566

product price: $24.59
/ea

Key Features

Material
Plastic
Includes
Installation Date Sticker
Manufacturers Warranty Length
5 yr
Calibration Certificate Included
No
Gauge Connection Size
1/4 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
PFE3932R1
Zoro #
G0405566
UPC #
628311257069
Country of Origin
China

Dimensions

Manufacturers Warranty Length
5 yr
Gauge Connection Size
1/4 in
Dial Size (In.)
3-1/2
Connection Size
1/4 in NPT
Diameter
3.874"
Gauge Nominal Dial Size
3 1/2 in
Nominal Dial Size
3 1/2 in
Manufacturer Warranty Length
5 yr
Process Connection Size
1/4 in
Case Diameter
3.681 in
Case Depth
1.228 in
Nominal Dial Diameter
3 1/2 in

Details

Item
Fire Sprinkler System Pressure Gauge
Material
Plastic
Includes
Installation Date Sticker
Calibration Certificate Included
No
Pressure and Vacuum Gauge Type
Pressure Gauge
Gauge Sensor Material
Phosphor Bronze
Gauge Connection Type
MNPT
Gauge Panel Mountable
No
Gauge Connection Location
Bottom
Gauge Lens Material
Polycarbonate
Basic Gauge Case Material
Plastic
Gauge Case Color
Black
Basic Gauge Socket Material
Brass
Basic Gauge Wetted Parts
Brass / Bronze
Series
PFE
Gauge Application
Ideally Suited for Fire Sprinkler Systems and Fire Fighting Equipment
Characteristics
Corrosion Resistant Case, CRN Registered, Suitable for Air Media, UL and FM Approved, Working Pressure is max. 75% of Full Scale Value
Range
0 to 80/retard/250 psi
Accuracy
+/-3-2-3%
Gauge Primary Range Values
0 to 80
Connection Location
Bottom
Basic Gauge Lens Material
Plastic
Liquid Filled
No
Gauge Case Material
Plastic
Max. Pressure (PSI)
250
Gauge Accuracy
+/-3.00%
Case Color
Black
Operating Temp. Range
-40 Degrees to 150 Degrees F
Gauge Primary Range Units
psi
Color
Black
Gauge Socket Material
Brass
Basic Gauge Sensor Material
Bronze
Application
Fire Fighting Equipment, Fire Sprinkler Systems
Socket Material
Brass
Case Material
ABS
Standards
ASME B40.100, CRN Registered, Factory Mutual, UL-393 for USA and Canada
Case Construction
Plastic
Hazardous Location Rating
Not Rated
Primary Pressure Range
0 to 80
Reads Head Pressure
No
Pointer Material
Aluminum
Bezel Mounting Type
No Bezel
Accuracy Grade
ASME B40.100 Grade B
Scale Type
Single
Removable Bezel
No
Accuracy Scale
Mid-Scale
Sensor Material
Bronze
Lens Material
Polycarbonate
Pressure Gauge Type
Fire Sprinkler System Gauge
Dial Color
White
Compatible Process Media
Air
Movement Material
Brass
Process Connection Location
Bottom
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F, -40 Degrees to 65 Degrees C
IP/NEMA Rating
IP52
Dial Face Material
Aluminum
Process Temperature Range
-40 Degrees to 150 Degrees F
Pressure Range Type
Pressure
Process Connection Type
NPT
Primary Scale Units
psi
Process Connection Gender
Male
Pointer Color
Black
Sensor Type
Bourdon Tube
Freeze Resistant Movement
No
Operating Temperature - Minimum
-40 Degrees F
Compatible with Brand
Universal
Includes Calibration Certificate
No
Process Media Temperature - Maximum
150 Degrees F
Liquid-Filled Case
No
Process Media Temperature - Minimum
-40 Degrees F
IP Rating
IP52
Operating Temperature - Maximum
150 Degrees F
NEMA Enclosure Rating
5
Primary Scale Pressure Measurement - Maximum
250 psi
Primary Scale Pressure Measurement - Minimum
80 psi
Case Liquid
None
Field Fillable
No

Description

Fire Sprinkler System Pressure Gauge, Nominal Dial Size 3 1/2 in, Accuracy +/-3-2-3 Percent, Gauge Case Material Plastic, Process Connection Type NPT, Process Connection Gender Male, Lens Material Polycarbonate, Process Connection Size 1/4 in, Field Fillable No, Process Connection Location Bottom, Case Color Black, IP/NEMA Rating IP52, Primary Pressure Range 0 to 80, Dial Color White, Pressure Gauge Type Fire Sprinkler System Gauge, Liquid-Filled Case No, Compatible Process Media Air
