Sensor Cables / Actuator Cables Mini-Change A Dble-End Cordset

  • Mfr # 1300100105

  • Zoro # G005782236


product price:  $150.99
/ea
Free Shipping & Returns

Key Features

Wire Size
16 AWG
Cable Length
5 m
Insulation Material
PVC
Cable Jacket Material
TPE
Maximum Voltage
600 V
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
1300100105
Zoro #
G005782236
UPC #
-
Country of Origin
Mexico

Dimensions

Wire Size
16 AWG
Cable Length
5 m
Length
16.4 ft
Cable Diameter
12.70mm (.500")

Details

Item
Cordset
Insulation Material
PVC
Cable Jacket Material
TPE
Maximum Voltage
600 V
IP Rating
IP67
Max. Amps
10 A
Maximum Operating Temperature
105 Degrees C
Color
Yellow
Material
PVC
Max. Voltage
600V
Standards
UL E152210
Type
Female-Male
Series
130010
Connector Type
Female-Male
Contact Finish
Gold Plated
Poles
5
Material - Contact
Copper Alloy
Protocol
DeviceNet
Connector End B
Mini-Change
Material - Plating Mating
Gold
Coupling Style
Threaded
Current - Maximum per Contact
8.0A
Orientation
Straight to Straight
Temperature Range - Operating
-20° to +105°C
LED Indicator
No
Material - Connector Body
TPE
UL
E152210
Wire/Cable Type
TC-ER
Material - Coupling Nut
Black Epoxy Coated Zinc
Connector End A
Mini-Change
Keyway
Single
Product Name
Mini-Change
