Shop YG-1 TOOL

TICN Plug Form Tap, M10x1.5 2.940 Groove

  • Mfr # ZC420

  • Zoro # G9685424

product price:  $28.95
/ea

Key Features

Drill Bit Size
#30
Weight
0.0944
Measurement System
Wire
Size
M10 - 1.5, D10
Connection(mm)
9.68 x 7.26
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
ZC420
Zoro #
G9685424
UPC #
-
Country of Origin
Korea, Republic of

Dimensions

Drill Bit Size
#30
Size
M10 - 1.5, D10
Entry Taper Length
4P - 5P
Shk. Dia.(metric)
9.68
Usable Length (in)
2.23
Drill Size(mm)
9.337000796
Sqr. Size(metric)
7.26
Usable Length (mm)
56.642
Size & Pitch
M10x1.5
Diameter(metric)
10
Shk. Dia.(inch)
0.381
Sqr. Size(inch)
0.286
Diameter(inch)
0.393700787
Length/Diameter
3.0 x D
Drill Size(inch)
0.367598457

Details

Item
Thread Forming Tap
Weight
0.0944
Measurement System
Wire
Connection(mm)
9.68 x 7.26
Connection(in)
0.381 x 0.286
OAL(metric)
74.68
Package(H)
0.625
OAL(inch)
2.94
System of Measurement
Inch
Number of Grooves
1
Sqr. Lgth.(metric)
11.18
Sqr. Lgth.(inch)
0.44
Package(L)
3.75
Blank Standard
302A
Thd. Lgth.(inch)
0.98
Number of Lobes
4
Thd. Lgth.(metric)
24.89
Pitch Limit
D10
Trade Name
YG Form Tap
Thread Series
M
Pitch
1.5
Package(W)
0.75
Entry Taper Type
Plug

Description

Thread Forming Tap
