Analog Panel Mt Thermometer, 0 to 100F

  • Mfr # 12U654

  • Zoro # G4256086

product price:
$
79.15
/ea

Key Features

Accuracy
+/-1 Degrees F Scale Division
Mounting
Surface with Bottom Outlet
Temp. Range (C)
17 Degrees to 37 Degrees
Temp. Range (F)
0 Degrees to 100 Degrees
Lens Material
Glass
See all product information
Unlock 30-day payment terms
Unlock 30-day payment terms
Business customers can apply for Net 30—no fees, no interest, fast approval. Terms apply.
Create Account
Get 10% off your order
Get 10% off your order
Sign up for our email list and receive your promo code via email.

Specifications

Product Information

MFR #
12U654
Zoro #
G4256086
UPC #
190735385951
Country of Origin
China

Dimensions

Sensor Length
1.87 in
Sensor Dia.
0.437 in
Tube Length
60 in
Dial Size
4 1/2 in
Cable Length
60 in
Probe Diameter
0.4 in
Thread Size
1/2 in
Flange Outside Diameter
5.9 in
Mounting Hole Diameter
1/5 in
Dial Diameter
4.5 in
Probe Length
2 in

Details

Item
Analog Panel Mount Thermometer
Accuracy
+/-1 Degrees F Scale Division
Mounting
Surface with Bottom Outlet
Temp. Range (C)
17 Degrees to 37 Degrees
Temp. Range (F)
0 Degrees to 100 Degrees
Lens Material
Glass
Case Material
Cast Aluminum
Sensor Material
Copper
Tube Material
Bronze Braided Copper
Sensing Medium
Vapor Actuated
Sensor Connection
1/2 in NPT
Maximum Temperature F
100 Degrees F
Sensor Technology
Vapor-Actuated
Housing Material
Aluminium
Minimum Temperature F
0 Degrees F
Thread Type
NPT
Thermometer Type
Remote Reading
Construction
Aluminium Housing with Glass Lens
Probe Material
Copper
Probe Built
0.4 in Dia x 2 in L Copper Probe
Temperature Range
0 Degrees to 100 Degrees F
Scale Type
Dial
Temperature Graduations
1 Degrees F
Thread Gender
Male
Process Connection
1/2 in MNPT with 5 ft Cable
NSF Rated
No
Scale
Fahrenheit
Mounting Style
Back Flange
Includes NIST-Traceable Certificate
No
Minimum Temperature °F
0 Degrees F
Maximum Temperature °F
100 Degrees F
Minimum Temperature °F
0 Degrees F
Maximum Temperature °F
100 Degrees F
Display Type
Dial
Product Type
Remote Reading Thermometer
Mounting Hardware
Back Flange
Temperature Units
Fahrenheit
Maximum Temperature (°F)
100 Degrees F

Description

Analog Panel Mount Thermometer, 0 Degrees to 100 Degrees F, 4.5 in, 0.4 in Dia x 2 in L Copper Probe, Probe Length 2 in, 1/2 in MNPT with 5 ft Cable, Vapor-Actuated, Aluminium Housing with Glass Lens, Cable Length 60 in
