Zoro Select Analog Panel Mt Thermometer, 30 to 240F 12U607 - main

Analog Panel Mt Thermometer, 30 to 240F

  • Mfr # 12U607

  • Zoro # G4255517

product price: $64.35
/ea

Key Features

Accuracy
+/-1 Degrees F Scale Division
Mounting
Bracket
Temp. Range (C)
1 Degrees to 115 Degrees
Temp. Range (F)
30 Degrees to 240 Degrees
Lens Material
Polycarbonate
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
12U607
Zoro #
G4255517
UPC #
190735385487
Country of Origin
China

Dimensions

Sensor Length
1.87 in
Sensor Dia.
0.437 in
Tube Length
60 in
Dial Size
3 1/2 in
Cable Length
5 ft
Probe Diameter
0.4 in
Dial Diameter
3.5 in
Thread Size
1/2 in
Mounting Hole Diameter
1/4 in
Probe Length
2 in

Details

Item
Analog Panel Mount Thermometer
Accuracy
+/-1 Degrees F Scale Division
Mounting
Bracket
Temp. Range (C)
1 Degrees to 115 Degrees
Temp. Range (F)
30 Degrees to 240 Degrees
Lens Material
Polycarbonate
Case Material
Stainless Steel
Sensing Medium
Vapor Actuated
Tube Material
Bronze Braided Copper
Sensor Connection
1/2 in NPT
Sensor Material
Copper
NSF Rated
No
Probe Material
Copper
Scale Type
Dial
Maximum Temperature F
240 Degrees F
Probe Built
0.4 in Dia x 2 in L Copper Probe
Thread Type
NPT
Thread Gender
Male
Process Connection
1/2 in MNPT with 5 ft Cable
Mounting Style
Bracket Mount
Temperature Range
30 Degrees to 240 Degrees F
Minimum Temperature F
30 Degrees F
Thermometer Type
Remote Reading
Construction
304 Stainless Steel Housing with Polycarbonate Lens
Includes NIST-Traceable Certificate
No
Temperature Graduations
2 Degrees F
Housing Material
304 Stainless Steel
Scale
Fahrenheit
Sensor Technology
Vapor-Actuated
Minimum Temperature °F
30 Degrees F
Maximum Temperature °F
240 Degrees F

Description

Analog Panel Mount Thermometer, Temperature Range 30 Degrees to 240 Degrees F, Dial Diameter 3.5 in, 1/2 in MNPT with 5 ft Cable, Includes NIST-Traceable Certificate No, Housing Material 304 Stainless Steel, Lens Material Polycarbonate
