  11. Cor Rad End Mill, 1", Carb, 1/4" rad
Zoro Select Cor Rad End Mill, 1", Carb, 1/4" rad 250-6406010B - main

Cor Rad End Mill, 1", Carb, 1/4" rad

  • Mfr # 250-6406010B

  • Zoro # G0575313

product price: $29.15
/ea

Key Features

Dimension Type
Fractional Inch
Corner Radius
0.25 in
Milling Diameter
1"
End Mill Material
Carbide
Number of Flutes
5
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
250-6406010B
Zoro #
G0575313
UPC #
888226276719
Country of Origin
United States

Dimensions

Dimension Type
Fractional Inch
Corner Radius
0.25 in
Milling Diameter
1"
Shank Dia.
1 in
Length of Cut
1.25 in
Milling Dia.
1 in
Overall Length
7 in

Details

End Mill Material
Carbide
Number of Flutes
5
Single End/Double End
Single
End Mill Cutting Type
Non-Center Cutting
Finish
nACRo
Grade
C2 Micro Grain
Cutting Direction
Right Hand
Primary Material Application
Aluminum, Brass, Bronze, Cast Iron, Copper, Hardened Steel, Steel, Tool and Die Steel
Super Alloy (S) Compatibility
Yes
Spiral Direction
Right Hand
Secondary Material Application ISO Code
K, M, P
List Number
255
Hardened (H) Compatibility
Yes
Primary Material Application ISO Code
H, K, N, P
Shank Type
Straight
Cast Iron (K) Compatibility
Yes
Finish - Machining
AlTiN
Min. Helix Angle
40 Degrees
Workpiece Compatibility
Cast Iron (K), Stainless (M), Steel (P), Super Alloy (S)
End Mill Style
Corner-Radius
Shank Type - Machining
Straight
Secondary Material Application
Cast Iron, Stainless Steel, Steel
Number of Coolant Holes
0
Steel (P) Compatibility
Yes
Material Grade - Machining
Micro Grain
Drilling Tool Configuration
Individual
Helix Angle
40 Degrees
Coolant Fed
Non-Coolant Through
Flute Type
Spiral
Material Applications
Cast Iron, Die Steel, Stainless Steel, Steel, Super Alloy
Item
Corner Radius End Mill
Stainless (M) Compatibility
Yes
Max. Helix Angle
40 Degrees
End Mill Application
Roughing/Finishing
Cutting Direction - Machining
Right Hand
Measurement System
Inch
Non Ferrous (N) Compatibility
No
Material - Machining
Carbide
Flute Spacing
Fixed

Description

Corner Radius End Mill, 1 in Milling Dia., Carbide, AlTiN, Non-Coolant Through, Straight, Inch, 0.25 in, 1.25 in, 7 in
