  11. Kingpinless Plate Caster, Swivel, Poly, 4 in., 500 lb
Zoro Select Kingpinless Plate Caster, Swivel, Poly, 4 in., 500 lb TSH100PT1HT24 - main

Kingpinless Plate Caster, Swivel, Poly, 4 in., 500 lb

  • Mfr # TSH100PT1HT24

  • Zoro # G2267501

product price: $108.99
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Swivel
Wheel/Tread Material
Polyurethane
Caster Brake Type
No Brake
Wheel Dia.
4 in
Wheel Width
1 1/2 in
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
TSH100PT1HT24
Zoro #
G2267501
UPC #
-
Country of Origin
United Kingdom

Dimensions

Wheel Dia.
4 in
Wheel Width
1 1/2 in
Mounting Height
6 1/8 in
Mounting Plate Size
5 3/4 in x 6 9/16 in
Mounting Plate Thickness
9/32 in
Mounting Bolt Dia.
1/2 in
Overall Height
6in
Mounting Plate Width
5 1/4 in
Outside Slot Spacing - Width
3.375 in
Mounting Plate Length
6 9/16 in
Overall Wheel Width
38 mm
Inside Slot Spacing - Length
4.938 in
Outside Slot Spacing - Length
5.25 in
Inside Slot Spacing - Width
2.438 in
For Axle Dia.
12 mm

Details

Item
Plate Caster
Caster Sub-Type
Swivel
Wheel/Tread Material
Polyurethane
Caster Brake Type
No Brake
Load Rating
480 lb
Wheel Bearing Type
Roller
Wheel/Tread Color
Tan
Wheel Hardness Rating
92 Shore A
Number of Mounting Holes
4
Tread Shape
Standard
Caster Frame Material
Steel
Core Color
Gray
Non-Marking
Yes
Number of Wheels
1
Outside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Inside Bolt Hole Spacing
2-7/16 in x 4-15/16 in
Caster Plate Hole Pattern
A
Caster Temp. Range Available
Yes
Replacement Wheel
Mfr. No. 100 PT1H
Standards
ANSI ICWM
Frame Finish
Enamel
Application
Kingpinless Casters
Includes
Top Grease Seal
Extended Lead
No
Caster Brake Included
No
Wheel Color
Tan
Thread Guards
No
Wheel/Tread Hardness Rating
Firm
Swivel Construction
Kingpinless
Load Rating Range
300 to 999 lb
Includes Thread Guards
No
Wheel Core Material
Iron
Swivel Lock Type
No Lock Included
Swivel Raceway Type
Single Ball
Load Capacity - Maximum
480 lb
Compatible With
100 PT1H
Wheel Core Type
Solid
Wheel Bearing Material
Steel
For Surface Type
Ceramic, Tile, Vinyl, Wood
Mounting Plate Shape
Rectangle
Mounting Hole Type
Slot
Operating Temperature Range
-22 Degrees to 176 Degrees F
Operating Temperature - Maximum
175 Degrees F
Operating Temperature - Minimum
-20 Degrees F

Description

Swivel, Plate Caster, Load Rating 480 lb, Swivel Lock Type No Lock Included, Wheel Dia. 4 in, Wheel Width 1 1/2 in, Wheel/Tread Material Polyurethane, Wheel Core Material Iron, Non-Marking Yes, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
