Zoro Select Plate Caster, Swivel, Phenolic, 8"H P29S-PH060R-18-WK-DL - main

Plate Caster, Swivel, Phenolic, 8"H

  • Mfr # P29S-PH060R-18-WK-DL

  • Zoro # G3577093

product price:  $245.99
/ea
Free Shipping & Returns

Key Features

Wheel Bearing Type
Roller
Extended Lead
No
Swivel Radius
7 1/16 in
Wheel Dia.
6 in
Wheel Width
3 in
See all product information
Get a 10% off coupon
Free 30-day returns Return Policy
Get 30 days to pay with Net 30 Apply Now
Unlock tax-exempt savings Add Tax Exemption

Specifications

Product Information

MFR #
P29S-PH060R-18-WK-DL
Zoro #
G3577093
UPC #
-
Country of Origin
China

Dimensions

Swivel Radius
7 1/16 in
Wheel Dia.
6 in
Wheel Width
3 in
Mounting Plate Size
5-1/4in x 7-1/4in
Mounting Bolt Dia.
1/2 in
Mounting Height
8 in
Overall Height
8in
Mounting Plate Width
5 1/4 in
Mounting Plate Thickness
3/8in
Outside Slot Spacing - Length
6.125 in
Inside Slot Spacing - Length
5.25 in
Inside Slot Spacing - Width
3.375 in
Overall Wheel Width
3 in
Outside Slot Spacing - Width
4.125 in
For Axle Dia.
3/4 in
Mounting Plate Length
7 1/4 in

Details

Wheel Bearing Type
Roller
Extended Lead
No
Item
Swivel Caster with Four Position Swivel Lock and Brake
Application
Dollies, Dough Troughs, Platform Trucks, Scrap Metal Carriers, Tooling Fixtures, Tow Lines, Utility Carts
Wheel Core Material
Phenolic
Non-Marking
Yes
Inside Bolt Hole Spacing
3-3/8 in x 5-1/4 in
Tread
Standard
System of Measurement
Inch
Replacement Wheel
Mfr. No. P-PH-060x030/075R
Core Color
Black
Caster Brake Included
Yes
Load Rating Range
Medium-Duty
Swivel Construction
Kingpin
Wheel Color
Black
Swivel Raceway Type
Double Ball
Swivel Lock Type
4-Position Directional Lock
Caster Sub-Type
Swivel
Tread Color
Black
Features
Floor Protective
Tread Shape
Standard
Thread Guards
No
Includes Thread Guards
No
Caster Mounting Type
Plate
Outside Bolt Hole Spacing
4-1/8 in x 6-1/8 in
Load Rating
2000 lb
Caster Plate Hole Pattern
A
Wheel/Tread Material
Phenolic
Caster Brake Type
Directional Lock, No Brake
Wheel/Tread Hardness Rating
Hard
Frame Finish
Zinc Plated
Caster Temp. Range Available
Yes
Number of Mounting Holes
4
Caster Frame Material
Steel
Number of Wheels
1
Standards
ANSI ICWM
Includes
Trailing End Brake, 4-Position Directional Lock
Wheel/Tread Color
Black
Series
P29 Series
ESD Conductive
No
Load Capacity
2000 lb
Resistant To
High Chemical Resistance To Many Aggressive Substances
Compatible With
P-PH-060X030/075R
Load Capacity - Maximum
2,000 lb
Wheel Bearing Material
Steel
Caster Features
Corrosion-Resistant
Mounting Plate Shape
Rectangle
Mounting Hole Type
Slot
Brake Location
Rear
Wheel Hardness Rating
Rockwell 102E
For Surface Type
Grease, Metal Scrap, Oil, Rubber, Steel, Wood
Wheel Core Type
Solid
Operating Temperature - Minimum
-20 Degrees F
Operating Temperature - Maximum
250 Degrees F
Operating Temperature Range
-40 Degrees To 250 Degrees F

Description

Swivel, Plate Caster, Load Rating 2000 lb, Swivel Lock Type 4-Position Directional Lock, Wheel Dia. 6 in, Wheel Width 3 in, Wheel/Tread Material Phenolic, Wheel Core Material Phenolic, Non-Marking Yes, Number of Wheels 1, Caster Brake Type Directional Lock, No Brake, Tread Shape Standard
