Zoro Select Pressure Gauge, Commercial, 0 to 30 psi, 2 in Dial, Acrylic Lens, 1/4 in MNPT, Plastic, Black 4FMC4 - main

Pressure Gauge, Commercial, 0 to 30 psi, 2 in Dial, Acrylic Lens, 1/4 in MNPT, Plastic, Black

  • Mfr # 4FMC4

  • Zoro # G0045534

product price:  $7.99
/ea

Key Features

Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Size
1/4 in
Process Connection Type
NPT
Application
Test and Measurement
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Unlock tax-exempt savings
Add Tax Exemption

Specifications

Product Information

MFR #
4FMC4
Zoro #
G0045534
UPC #
190735507759
Country of Origin
China

Dimensions

Process Connection Size
1/4 in
Dial Size (In.)
2 in
Nominal Dial Size
2 in

Details

Item
Commercial Pressure Gauge
Accuracy
+/-3-2-3%
Process Connection Location
Center Back
Process Connection Type
NPT
Application
Test and Measurement
Gauge Case Material
ABS Plastic
Lens Material
Acrylic
Primary Pressure Range
0 to 30
Primary Scale Units
psi
IP/NEMA Rating
Not Rated
Liquid-Filled Case
No
Hazardous Location Rating
Not Rated
Panel-Mountable
No
Blowout Safety Back
No
Gauge Primary Range Smallest Graduation
0.5
For Use With
Air and Noncorrosive Fluids Such as Water and Oil in Pumps, Filters, Compressors, and Regulators
Calibration Certificate Included
No
Gauge Secondary Range Values
0 to 200
Gauge Application
General-Purpose Case
Smallest Graduation
0.5 psi
Case Color
Black
Case Material
ABS Plastic
Socket Material
Brass
Connection Type
MNPT
Wetted Materials
Brass / Bronze
Dial Color
White
Vibration Resistance
None
Gauge Case Liquid
None
Sensor Material
Bronze
Includes Mounting Hardware
No
Ambient Operating Temperature Range
-40 Degrees to 150 Degrees F
Process Connection Gender
Male
Secondary Scale Units
kPa
Pressure Gauge Type
General Purpose Dial Pressure Gauge
Field Fillable
No
Bezel Material
Crimped Stainless Steel
Scale Type
Dual
Accuracy Scale
Mid-Scale
Cleaned for Oxygen Service
No
Non-Sparking
No
Includes Vent Plug
No
Secondary Pressure Range
0 to 200
Freeze Resistant Movement
No
Primary Scale Minor Graduations
0.5
Pressure Range Type
Pressure
Dry Dampening Feature
None
Removable Bezel
No
Includes Calibration Certificate
No
Maximum Pressure
30
Operating Temperature Range
-40 Degrees to 150 Degrees F

Description

Commercial Pressure Gauge, Accuracy +/-3-2-3 Percent, Gauge Case Material ABS Plastic, Nominal Dial Size 2 in, Lens Material Acrylic, IP/NEMA Rating Not Rated, Hazardous Location Rating Not Rated, Sensor Material Bronze, Socket Material Brass, Process Connection Type NPT, Process Connection Gender Male, Process Connection Location Center Back, Process Connection Size 1/4 in, Panel-Mountable No, Pressure Gauge Type Commercial Pressure Gauge
