  11. Rigd Sold Rubr Whl Cstr, 9-7/8 in, 1000 lb
Zoro Select Rigd Sold Rubr Whl Cstr, 9-7/8 in, 1000 lb B-VLE 250K - main

Rigd Sold Rubr Whl Cstr, 9-7/8 in, 1000 lb

  • Mfr # B-VLE 250K

  • Zoro # G4538107

product price: $317.99
/ea
Free Shipping & Returns

Key Features

Caster Sub-Type
Rigid
Caster Product Group
Rigid Caster
Load Rating
990 lb
Wheel Dia.
250 mm
Wheel Width
85 mm
See all product information
Get a 10% off coupon
Free 30-day returns
Return Policy
Get 30 days to pay with Net 30
Apply Now
Real support from real people
Contact our U.S. based team

Specifications

Product Information

MFR #
B-VLE 250K
Zoro #
G4538107
UPC #
-
Country of Origin
Germany

Dimensions

Wheel Dia.
250 mm
Wheel Width
85 mm
Mounting Height
11 5/8 in
Mounting Plate Size
4-3/4 in x 8-11/16 in
Mounting Bolt Dia.
M14
Overall Height
295 mm
Plate Thickness
5/32"
Plate Size
4-3/4 x 8-11/16"
Caster Plate Thickness
4 mm
Caster Plate Size
120 mm x 220 mm
Hub Width
2-15/16 in
Tire Rim Dia.
4"
Tire Thickness
2-1/2"
For Axle Dia.
16 mm
Bolt Hole Spacing - Length
7.469 in
Mounting Plate Thickness
5/32 in
Mounting Plate Length
5 1/8 in
Bolt Hole Spacing - Width
2.969 in
Overall Wheel Width
3 3/8 in

Details

Item
Rigid Plate Caster
Caster Sub-Type
Rigid
Caster Product Group
Rigid Caster
Load Rating
990 lb
Wheel/Tread Material
Rubber
Wheel/Tread Hardness Rating
Soft
Wheel Bearing Type
Ball
Mounting Plate Bolt Hole Pattern
D
Inside Bolt Hole Spacing
75 mm x 190 mm
Outside Bolt Hole Spacing
75 mm x 190 mm
Number of Mounting Holes
4
Caster Brake Type
No Brake
Non-Marking
No
Number of Wheels
1
Frame Finish
Zinc Plated
Caster Frame Material
Steel
Wheel Core Material
Pressed Steel
Core Color
Silver
Application
Retail, Industrial, Commercial
Standards
RoHS, ICWM
Includes
Top Grease Seal
Caster Load Rating Range
Medium Duty
Tread
Ribbed
Caster Temp. Range Available
No
Plate Caster Bolt Hole Pattern
D
Caster Wheel/Tread Material
Super Elastic Solid Rubber
Frame Material
Steel
Caster Plate Hole Pattern
D
Caster Wheel Bearings
Precision Ball
Hub Color
Gray
Wheel/Tread Hardness
70 Shore A
Replacement Wheel
Mfr. No. VLE 250/20-75K
Includes Thread Guards
No
Extended Lead
No
Tread Color
Black
Caster Brake Included
No
Caster Swivel Lock Type
No Lock Included
Hub Type
Centered
Hub Material
Steel
Caster Mounting Type
Plate
Caster Temp. Range
-25 Degrees To 80 Degrees C
Ply
2
Wheel Type
Flat-Free
Load Capacity
450 kg
Operating Temperature Range
-20 Degrees to 180 Degrees F
Resistant To
Chemical Resistance To Many Aggressive Substances, Except Oils
ESD Conductive
No
System of Measurement
Metric
Tread Shape
Ribbed
Caster Break Type
No Brake Included
Series
B Series
Wheel Hardness Rating
70 Shore A
Load Capacity - Maximum
990 lb
Wheel Bearing Material
Steel
Mounting Plate Shape
Rectangle
For Surface Type
Asphalt, Ceramic, Grease, Rubber, Steel
Mounting Hole Type
Hole
Caster Features
Corrosion-Resistant, Debris-Resistant, Maintenance Free, Quiet-Roll
Wheel Core Type
Solid

Description

Rigid, Plate Caster, Load Rating 990 lb, Wheel Dia. 10 in, Wheel Width 3 3/8 in, Wheel/Tread Material Rubber, Non-Marking No, Number of Wheels 1, Caster Brake Type No Brake, Tread Shape Standard
